Thr-Eb5301 High-Level Five Function Electrical Bed with Weigh Readings
| Model NO. | THR-EB5301 |
| Type | Electric Bed |
| Using Ambient | Hospital |
| Bed | Hospital ICU Bed |
| Patient Touching Surface | 90*196mm |
| Bed Frame | Cold-Rolled Steel Tube |
| Size | 2230*990*520/820mm |
| Specification | CE, ISO, TUV |
| Material | ABS |
| Folded | Unfolded |
| Certification | CE, ISO13485 |
| Safety Load | 250kg |
| Height Adjustment | 520mm-820mm |
| Bed Base | Cold-Rolled Steel Sheet |
| Trademark | THR |
| Origin | China(Mainland) |
THR-EB5301 High-level Five Function Electrical Bed with weigh Readings
Specification
Length223 cm
Width(Including & Without the side rails)99~105 cm05 cm05 cm
Patient touching face90*160 cm
Maximum capacity250kg
Diameter of Central controlled castors12.5 cm
Accuracy of Measurement0.1kg
Material
Top coatElactrostatic Powder coating
Bed frameCold-Rolled Steel Tube
Bed baseCold-Rolled Steel Sheet
Function
Adjustable angle of Back Section Panel 0~75°°deg;°
Adjustable angle of Leg Section Panel0~45°°deg;°
Trendelenburg0~10°°deg;°
Anti-Trendelenburg0~10°°deg;°
Height range52~76 cm
Standard Accessary
Nurse controller1 unit
Rail controller4 units
Linak Electrical Motor4 units
Drainage hook2 units
Angle scale2 units
Manual CPR Handle1 unit
Central silent castors4 units
Detachable ABS head and foot board1 pair
Rise-and-fall guide wheel1 unit
Optional Accessary
-I. V Pole with 4 hooks
-Waterproof ventilative Mattress
-Weight reading sysytem
-Accuracy of Measurement of 0.05kg or 0.02kg
Picture Show
Specification
Length223 cm
Width(Including & Without the side rails)99~105 cm05 cm05 cm
Patient touching face90*160 cm
Maximum capacity250kg
Diameter of Central controlled castors12.5 cm
Accuracy of Measurement0.1kg
Material
Top coatElactrostatic Powder coating
Bed frameCold-Rolled Steel Tube
Bed baseCold-Rolled Steel Sheet
Function
Adjustable angle of Back Section Panel 0~75°°deg;°
Adjustable angle of Leg Section Panel0~45°°deg;°
Trendelenburg0~10°°deg;°
Anti-Trendelenburg0~10°°deg;°
Height range52~76 cm
Standard Accessary
Nurse controller1 unit
Rail controller4 units
Linak Electrical Motor4 units
Drainage hook2 units
Angle scale2 units
Manual CPR Handle1 unit
Central silent castors4 units
Detachable ABS head and foot board1 pair
Rise-and-fall guide wheel1 unit
Optional Accessary
-I. V Pole with 4 hooks
-Waterproof ventilative Mattress
-Weight reading sysytem
-Accuracy of Measurement of 0.05kg or 0.02kg
Picture Show
| Specification | |
| Length | 223 cm |
| Width(Including & Without the side rails)ails)ails) | 99~105 cm |
| Patient touching face | 90*160 cm |
| Maximum capacity | 250kg |
| Diameter of Central controlled castors | 12.5 cm |
| Accuracy of Measurement | 0.1kg |
| Material | |
| Top coat | Elactrostatic Powder coating |
| Bed frame | Cold-Rolled Steel Tube |
| Bed base | Cold-Rolled Steel Sheet |
| Function | |
| Adjustable angle of Back Section Panel | 0~75°°deg;° |
| Adjustable angle of Leg Section Panel | 0~45°°deg;° |
| Trendelenburg | 0~10°°deg;° |
| Anti-Trendelenburg | 0~10°°deg;° |
| Height range | 52~76 cm |
| Standard Accessary | |
| Nurse controller | 1 unit |
| Rail controller | 4 units |
| Linak Electrical Motor | 4 units |
| Drainage hook | 2 units |
| Angle scale | 2 units |
| Manual CPR Handle | 1 unit |
| Central silent castors | 4 units |
| Detachable ABS head and foot board | 1 pair |
| Rise-and-fall guide wheel | 1 unit |
| Optional Accessary | |
| -I.V Pole with 4 hooks | |
| -Waterproof ventilative Mattress | |
| -Weight reading sysytem | |
| -Accuracy of Measurement of 0.05kg or 0.02kg | |
