Five-Function Electric ICU Hospital Bed

Five-Function Electric ICU Hospital Bed

bargain

add to cart
Model NO. THR-EB5300
Folded Folded
Weight Scale System Optional
End Board Control System Available
Functions Five Functions
OEM Available
Motors Linak Motor: Five Year Warranty
Specification CE and ISO
Material Metal
Size 2220*990/1050*450-790 Mm
Castors Central Control Castors
Insulted Side Rails Control Board Available
CPR Handle Optional
Color Optional Blue, Wood Color
Trademark THR
Origin China
Five-Function Electric ICU Hospital Bed (THR-EB5300)
1)ISO, CE Electric Hospital Bed
2)With five function
Technical Parameters:
1. Over all size (L*W*H): 2220*990/1050*450/790mm
2. Maximum Low- 45cm
3. Maximum height---79cm
4.12.5cm castor
5. Four independence motors.
6. Built in foot board's I. V. Pole
7. Control button for outside of side rails and foot board
8. Control button for inside of side rail.
9. Angle scale.
10. CPR handle.
11. Detachable head and foot board
12. Retractable fifth wheel (optional)
13. Electronic function Lock (optional)
14. Weight rendings system: Accuracy of measurement -0.1kg
Features:
1. The security, reliability and practicability of the hospital bed attain national standard.
2. Its in-bed scale system increase efficiencies by taking accurate weight readings with the patient in any position.
3. It addresses patient safety with low bed height, full coverage side rails.
4. Its architecture and retractable support surface designed provides the flexibility to choose the most appropriate patient surface.
5. Patient will feel very convenient while be on drip or used the heart monitor since it won't need to change patient position when the bed back section rise and low.
Specification
Length: 223 cm
Width: (Including & Without the side rails)ails)ails) 99~105 cm
Patient touching face: 90*160 cm
Maximum capacity: 250kg
Diameter of Central controlled castors: 12.5 cm
Accuracy of Measurement: 0.1kg
Material
Top coat: Elactrostatic Powder coating
Bed frame: Cold-Rolled Steel Tube
Bed base: Cold-Rolled Steel Sheet
Function
Adjustable angle of Back Section Panel: 0~75°°deg;°
Adjustable angle of Leg Section Panel: 0~45°°deg;°
Trendelenburg: 0~10°°deg;°
Anti-Trendelenburg: 0~10°°deg;°
Height range: 45~70 cm
Standard Accessary
Nurse controller 1 unit
Rail controller 4 units
Linak Electrical Motor 4 units
Drainage hook 2 units
Angle scale 2 units
Manual CPR Handle 1 unit
Central silent castors 4 units
Detachable ABS head and foot board 1 pair
Rise-and-fall guide wheel 1 unit
Optional Accessary
I. V. Pole with 4 hooks
Waterproof ventilative Mattress
Weight reading sysytem
Accuracy of Measurement of 0.05kg or 0.02 kg
Packing Information
Packing size: 244L*99W*53H cm
