Full (Wide) scene imaging
Extend the (extended) pulse imaging (EPI)
Real-time 3D/4D synchronization imaging
Trapezoidal extended imaging
Anatomical M-mode imaging
Elasticity imaging (ELASTOGRAPH)
1.10 Inverting pulse harmonic imaging
1.11 A key optimization (optimize 2D gray-scale images and PW images)
1.12 Multi lingual user interface optional, Chinese/English operation interface, support for Chinese/English input.
1.13 Real-time synchronization unit: 2D, color Doppler, spectral Doppler / continuous CWD at the same time the same screen real-time display.
1.14 Professional package: Abdomen, obstetrics and gynecology, small parts, urology, orthopedic surgery, cardiac
1.15 Measurement: Distance, area, angle, time, slope, heart rate, speed, acceleration, spectrum tracing, resistance index and pulsate index
1.16 Gain: B / PW / CD can be separately adjusted
1.17 Movie playback ≥ 1000 frameframerame
2. Probe configuration and specifications:
2.1 Configuration: Convex array probe, the high-frequency linear array probe, transvaginal probe
2.2 convex array probe: 2.5-5.0 MHz center frequency: ≥ 3, visual adjustable; With harmonic imaging capabilities, the harmonic frequency of ≥ 2, visual adjustablejustableustable
2.3 linear probe: 6.0-10.0 MHz center frequency: ≥ 3, visual adjustable; With harmonic imaging capabilities, the harmonic frequency≥ 2, visual adjustableustableustable
2.4 Transvaginal probe: 5.0-8.0 MHz (scan angle ≥ 130° )30° ); )30° )
2.5 Variable frequency phased array cardiac probe: The frequency range 2 - 4MHz, 3 frequency bandwidth is optional; Probe scanning angle: 10° To 85° . 85° .; . 85° .
3.2D imaging modes:
3.1 4B imaging mode
3.2 B-type images in real time and freeze the zoom magnification of ≥ 8, 10 or more adjustabletableable
3.3 Grayscale: 256
3.4 Position chart: ≥ 60e; 60; 60
3.5 Dynamic range: 0-150dB, visual adjustable 10 level and above
3.6 The probing depth: ≥ 360mm360mm60mm
3.7 Resolution: Lateral ≤ 2mm; Vertical ≤ 1mm≤ 1mmmm≤ 1mm
3.8 Focus: B mode, the focus position and focus distance is adjustable
3.9 Ultrasonic power output: ≥ 10 adjustabletableable
3.10 Preconditions: ≥ 10 species, the user can customize the conditionstionsions
3.11 Pseudo-color display: ≥ 7 specieseciescies
3.12 Convex array probe: 18cm depth, full aspects, 2D frame rate≥ 30 frames / sec. sec.sec.
3.13 Linear array probe beam deflection
3.14 Digital beam formation: Continuous dynamic focusing, variable aperture and dynamic change trajectory
3.15 B, 2B, 4B display modes
3.16 TGC segment gain adjustment ≥ 8 segmentsmentsents
4. M model
4.1 B / M to a variety of layout adjustable
4.2 M scanning speed is adjustable
5. Color Doppler:
5.1 Color gain and PRF multi-level adjustable
5.2 Visual Color frequency adjustable: ≥ 2ge; 2e; 2
5.3 Sampling frame: The size and position adjustable
5.4 Color Atlas: ≥ 7ge; 7e; 7
5.5 Color afterglow: ≥ 4ge; 4e; 4
5.8 Color baseline adjustable
Color Doppler energy diagram:
6.1 The direction of the energy diagram
6.2 Energy in gain: Adjustable
6.3 The energy diagram
7. Doppler spectrum:
7.1 Doppler spectrum of the emission frequency can be multi-file variable frequency
7.2 The measurement speed: The minimum detectable speed of 1mm / s maximum speed measurement ≥ 25m / s, / s,/ s,
7.3 Sample volume size: 1mm-15mm, adjustable
7.4 Sampling point of correction: -70 ° To 70°To 70°eg;To 70°
7.5 Spectrum Gain: Adjustable;
7.6 Spectrum Automatic tracing and automatic measurement functions,
