Technical Specification

B&W mode: B,M,2B,B/M,4B
Gray sacle: 256
Display: 15'LCD monitor
Transducer frequency: 2-11Mhz
Digital technology: Wide-angle imaging
Panoramic focusing technology
Rolling M technology
Scanning depth: 300mm
Imaging Processing
Pre-processing: Cloud processing technology
8-segment TGC
Gain(B&W)
Dynamic range
Persisitence
M Soften
Noise suppression
Post-processing: Image enhancement
Gray Map
Colorize Map
Tissue Specific Imaging
Left/right reverse
Up/down reverse
Functions
Cine-loop: 334 frame cine loop memory
USB ports: 2
Zoom: Pan zoom
THI: Tissue Harmonic Imaging
Qopt: Optimize
DICOM 3.0: DICOM 3.0
Measurement & Calculations
B mode: Distance, angle, area, volume, trace length, distance ratio
M mode: Distance, time, slope, HR
Software packages: Abdomen, OB, gynecology, small Part
Others
Transducer connector: 2 active transducer connector ports
Peripheral ports: Video,2 USB ports,1 networking port,1 power inlet,1 equipotential
terminal

Power supply: AC 100-240V 50/60HZ ﹤80VA
Dimensions(main unit): 358mm(W)´366mm (L)´65mm (H)
Packing dimensions : 378mm(W)´376mm(L)´85mm(H)
Net weight: Approximately 4.0kg
Gross weight: Approximately 5.0kg

Multi-frequency probes

3.5 MHz convex probe
Application:
Abdomen,GYN,OB


7.5 MHz linear probe
Application:
Vascular,Small Parts


6.5 MHz trans-vaginal probe
Application:
Vaginal


5.0 MHz micro-convex probe
Application:
Cardiac

Standard Configurations




Optional
3.5 MHz convex probe
7.5 MHz linear probe
6.5 MHz trans-vaginal probe
5.0 MHz micro-convex probe
