Ce Approved Hospital ICU Medical Instrument Syringe Pump X-Pump S9
| Model NO. | X-Pump S9 |
| Certification | CE, ISO13485 |
| Medical Device Regulatory Type | Type 2 |
| Status Indicator | Stop, Run, Bolus, Kvo |
| Syringe Type | 5, 10, 20, 30, 50 Ml |
| Accuracy | +/-3% |
| Weight | Approximately 1.8 Kg |
| Power Supply | 100 - 240 VAC, 0.25-0.11A, 50/60 Hz |
| Transport Package | Carton Box |
| Origin | Shenzhen, China |
| Type | Syringe Pump |
| Group | All Patient |
| Display Screen | 3.5 Inch B/W LCD |
| Battery Type | Lithium Polymer Battery(7.4V) |
| Accumulated Injection Volume | 0.1 - 999.9 Ml |
| Increment | 0.1ml/H |
| Waterproof Level | IP23 |
| Trademark | BMV |
| Specification | 310 mm(L) * 125 mm(D) *115 mm(H) |
| HS Code | 9018310000 |
X-Pump S9 Syringe Pump
designed for neonatal, pediatric and adult patients in the ICU and OR.
Product Features
Drug library with all the most used drugs
History record review and last configuration memory
Change the flow rate while operating
Manual bolus and automatic bolus
Anti-bolus system to reduce significantly bolus after occlusion sudden release
Micro flow rate of 0.1ml/h and Body weight mode to satisfy the requirement for Neonatal
Wireless data transmission with infusion supervision system (optional)
Specification list
designed for neonatal, pediatric and adult patients in the ICU and OR.
Product Features
Drug library with all the most used drugs
History record review and last configuration memory
Change the flow rate while operating
Manual bolus and automatic bolus
Anti-bolus system to reduce significantly bolus after occlusion sudden release
Micro flow rate of 0.1ml/h and Body weight mode to satisfy the requirement for Neonatal
Wireless data transmission with infusion supervision system (optional)
Specification list
| Applicable syringes | All brands of standard syringes: 5ml,10ml,20ml,30ml,50ml |
| Accuracy | ±3%lusmn;3%lusmn;3% |
| Injection increment | 0.1ml |
| Occlusion value | 40kPa~160kPa |
| Injection rate | 5ml: 0.1 ml/h~100ml/h; 10ml: 0.1 ml/h~200ml/h 20ml: 0.1 ml/h~400ml/h; 30ml: 0.1 ml/h~600ml/h; 50ml: 0.1 ml/h~1500ml/h |
| Accumulated injection volume | 0.1ml~9999.9ml |
| Modes of operation | Selectable: rate mode, time mode, body weight mode |
| Time mode | Volume limit: 0.1~999.9ml Time: 1~2000 minutes |
| Body weight mode | Drug limit:0.1~999.9mg Solution limit:0.1~999.9ml Weight: 01~300.0kg Dose: 0.1~9999.9 mg/kg/h, ug/kg/min |
| Displayed information | Rate, volume limit, accumulated injection volume, syringe size, pressure value, battery capacity, unit of medical dosage, bed No., AC power indicator, battery charge indicator, drug name, bolus rate |
| Alarm function | OVER, NEAR, Occlusion, Low battery, Syringe disengaged, No AC power supply, serious low battery |
| KVO rate | 0.1ml/h~5.0ml/h (selectable) |
| Bolus rate | 5ml: 100ml/h; 10ml: 200ml/h; 20ml: 400ml/h; 30ml: 400ml/h~600ml/h; 50ml: 400ml/h~1500ml/h |
| Weight | 1.8kg |
| Dimension | 310 X 125 X 115mm |
| Power supply Fuse | AC100~220V, 50/60Hz T2AL250AV |
| Maximum power consumption | 25W, can run for 4h after being recharged |
| Battery | Rechargeable lithium polymer battery, 7.4V, 1600mAh |
| Battery recharge | When the pump is connected to the AC power supply, turn on the power and the battery will automatically recharge (about 8~14 hours to recharge fully) |
| Electrical safety | Comply with the stipulation of IEC60601-1: 1996 |
| Electromagnetic compatibility | Comply with the stipulation of IEC60601-1-2: 2006 |
| Shell material | ABS plastic |
| Classification | II Class-BF |
| Operating conditions | Environment temperature: 5°C~40°C~40°Ceg;C~40°C air pressure: 80kPa~106kPa relative humidity ≤ 80% 80% 80% |
| Storage conditions | Environment temperature: -20°C~50°C~50°Ceg;C~50°C air pressure: 50kPa~106kPa relative humidity ≤ 95% 95% 95% |
