Electrical Nursing Bed for best price MSLNB01





1, Use
Electrical Nursing Bed is designed for healing, diagnosis and treatment.


2, Main characteristic:
A. Both ends of beds are made of ABS materials and detachable.
B. The main body is made of sprayed high-quality carbon steel.
C. Equipped with central-controlled φ 125mm castors, stable; To reduce friction with ground, easy to move.
D. Cold-rolled steel plate is used in the tabletop.
E. It used high-quality electric-vat, look nice, save electricity, lower noise, waterproof, long life-span.


3, Main Structure
The product is composed of the mechanism and the electric control system.
The rotation and movement of back-care bed frame, legs frame and its raising and lowing of electric nursing bed are driven to the various adjustable positions by motor, if necessary, can be adjusted at your choice.


4, Technical Parameters:
Supply: AC 220V± 10%, 50Hz
Length...2050mm
Width...900mm
Min Height...430mm
Max Height...680mm
Adjust...190mm
Back Section Raised from the horizontal...≥ 60°
Leg Section Raised from the horizontal...≥ 30°
Security Load...1750N
Device safety sort I B


5, Install Step
Install bed head, bed end.
Four fixed-axis must be rotated to the bed frame tightly, then insert Head bed rack and Tail bed rack into them.


6, Instruction of Electric Nursing Bed:
A. When four foot-wheels is free, then bed can be moved. When foot-wheels be braked, the bed is fixed.
B. To facilitate patients on the bed, pulling upward the guardrail, flip down 180 ° , then put aside the guardrail. On the contrary, the guardrail can be erected.
C. Back section and leg section Fold up and down, ascending and descending movements of the bed top are all electrically operated. When the necessary button is rushed, the corresponding motor will work, when the button is not puessde, all movements stop.


Cautions:
1, Before using the bed, lock all handles tightly.
2, Keep the button container dry and clean to avoid current leakage.
3, Keep the bed clean and look nice.
4, It must be repaired and kept clean regularly, once every year.
5, In unattended circumstances, the mattress supporting table should be placed in the horizontal position
6, Move bed, please put wires hanging on the wires hook to avoid roller pressing the wires, which can result in the wire fracture or wire insulation damage, affecting manipulation.
7, The product can electrically operate 6 movements. These movements must be operated separately. Attention: The product is supplied by single-phase alternating current (220V, 50Hz), tri-socket. Fuse plug rating is 2A. Please carefully inspect socket to insure reliable earth; Shut off power while stop perform.
8, The service life for the bed is seven years. If it is used in expired period, it maybe LED to wearing and corrosion of some mechanical parts, and had a negative influence upon the mechanical intensity. The patients maybe suffered. So the bed should be used in the regular maintenance and during safety using period.
9, Patients must be in the normal state of mind, body weight must not exceed 135 kg.
10, The replacement parts during the bed' normal using period, has been confirmed scrapped (unable to use), should be handled according to the classification (recyclable and non-recovery).
11, Electric care beds coupled with the use of high-frequency surgical equipment, it is possible that electromagnetic interference happens, therefore, it should avoid operating directly to the bed when using both.
