Portable Anesthesia Equipment (THR-MJ-P902)
| Model NO. | THR-MJ-P902 |
| Certification | CE, ISO13485 |
| Ventilation Method | Closed, Semi-Closed, Semi-Open |
| O2 Flush | More Than 25L/Min |
| TV (Tidal Volume) | 50-2000ml |
| Three Gauges | One for O2, One for N2o, One for Airway Pressure |
| Application | Adult, Pediatric |
| Specification | CE and ISO |
| Type | Anaesthesia Machine |
| LCD Display | Without LCD Display |
| Gas Source | O2, N2o, 0.25mpa-0.65mpa |
| Respiratory Mode | Manual, Oxygen |
| Monitoring | Airway Pressure, Respiratory Mode |
| Size | 380mm (W) *360mm (H) * 180mm (L) |
| Trademark | THR |
| Origin | China |
Portable Anesthesia Equipment (THR-MJ-P902)
Feature:
CE Certificated
Module rack with polyester medical material, high strength and light weight.
Superior thin spray technology, delicate color, beautiful and durable.
High precious vaporizer, halothane, enflurane, isofurane and sevoflurane could be choosed freely.
Main unit are only 2kg (W/O vaporizer), light weight and easy to move.
With a dedicated handle, could move by hand-pull.
Two gas source: O2, N2O, suitable for more patient type.
Small and compact unit ideal for office based anaesthesia
Mechanical anti-hypoxic device and O2/N2O interlock
External CO2 circle absorber system
Ventilator(option): TH-1, TH-1A
Feature:
CE Certificated
Module rack with polyester medical material, high strength and light weight.
Superior thin spray technology, delicate color, beautiful and durable.
High precious vaporizer, halothane, enflurane, isofurane and sevoflurane could be choosed freely.
Main unit are only 2kg (W/O vaporizer), light weight and easy to move.
With a dedicated handle, could move by hand-pull.
Two gas source: O2, N2O, suitable for more patient type.
Small and compact unit ideal for office based anaesthesia
Mechanical anti-hypoxic device and O2/N2O interlock
External CO2 circle absorber system
Ventilator(option): TH-1, TH-1A
| Ventilation Method: | Closed, Semi-closed, Semi-open |
| Application | Adult, Pediatric |
| Gas Source | O2, N2O, 0.25mpa-0.65mpa |
| Two-tube (O2,N2O) | Scope, 0-10L/min. With linkage device, O2 concentration not low than 25%. |
| O2 flush | More than 25L/min |
| Respiratory mode | Manual, Oxygen |
| TV (Tidal volume) | 50-2000ml |
| I:E | According to the doctor operation |
| BPM | According to the doctor operation |
| APL valve pressure | 0.5-6Kpa |
| Monitoring | Airway pressure, respiratory mode |
| Three Gauges | One for O2, one for N2O, one for airway pressure. |
| Temperature | Operation: 18-36 ºCordm;Cordm;C Storage: -20-55 ºCordm;Cordm;C |
| humidifier | Operation: 45%-75% Storage: ≤93%;93%;93% |
| Atmospheric pressure | Operation: 0.95-1.05 bar Storage: 500hpa-1060hpa |
| Altitude | Operation: 500 to 800 mmHg (3565 to -440m) Storage: 375 to 800 mmHg (5860 to -440m) |
| Size | 380mm (W) *360mm (H) * 180mm (L) |
| weight | 9kg |
| Model | TH-1 | TH-1(A) | |
| Display: | High light LED display | 5.5' SNT LCD screen | |
| Ventilation mode: | Volume mode and Manual mode | IPPV, SIMV, MANUAL | |
| Tidal volume: | 50 ~ 1500ml | 50 ~ 1600ml | |
| Breath frequency: | 1~ 90 BPM | 1~ 65 BPM | |
| I:E ratio: | 4:1 ~ 1:6 | 8:1 ~ 1:8 | |
| Monitor parameter: | Tidal volume, breath frequency, MV | Tidal volume, MV, Ppeak, PEEP, respiratory frequency, I:E ratio | |
| Alarm: | MV high alarm, MV low alarm, TV high alarm, TV low alarm | High pressure alarm, 20 ~ 60cmH2O Low pressure alarm, 0 ~ 20cmH2O O2 source lost alarm, AC power lost alarm Safety valve pressure limit: 6Kpa | |
