CE Approved Medical Portable Electric Syringe Pump
| Model NO. | HSP-3 |
| Medical Device Regulatory Type | Type 2 |
| Certificate | CE ISO |
| Power Supply | AC220V±22V/50Hz±1Hz/50Hz±1Hzmn;1Hz/50Hz±1Hz |
| Size (mm) | 320(L)X145(W)X120(H) |
| Consume Power | ≤10va;10va10va |
| Block Pressure | 40~70kpa |
| Specification | CE, ISO |
| HS Code | 9018909090 |
| Medical Devices Reg./Record No. | Ssyjxzz20122210576 |
| Warranty | 12months |
| Relative Humidity | ≤80%Rh80%Rh0%Rh |
| Atmospheric Pressure | 860hpa~1060hpa |
| Weight | About 3kg |
| Frequency | 50Hz±1Hzlusmn;1Hzusmn;1Hz |
| Trademark | Healicom |
| Origin | Jiangsu, China |
Introduction: Using new technology of microcomputer, compact structure and convenient operation, HSP-3 syringe have multi-warning functions and could use various injectors. HSP-3 syringe pump is suitable for generic medicament and unsuitable for stupefacient, anodyne, insulin, chemotherapy medicine, etc.
Work Term
Technique Parameter:
HSP-3 Syringe Pump's Advantages
1. Our syringe pump could use all brands through calibration (default setting is Terumo), syringes including 10ml, 20ml, 30ml, 50ml.
2. Auto-recognize the syringe size: 10, 20, 30, 50ml.
3. Available for adjust alarm volume (3 levels), standby alarm delay time (1-9min), nearly finish alarm interval (0-3min).
4. Power Switching Function: When AC power is disconnected, automatically switch into battery power supply and give indication. When the AC power is connected, automatically switch into AC power working.
5. Repeat Alarm Function: If the alarm real reason is not be resolved within 2 minutes after press 'SILENCE' button, it will give alarm again to remind to resolve the problem.he problem.
6. Battery Protection Alarm: For protect battery and safety infusion, the battery power will be displayed as different levels in sound and light from nearly finish to exhausted.
7. Double confirmation function when flow rate≥300ml/h, make safer and avoid misoperation.ion.ion.
8 The data can be cleared, make safer.
9. Lock the control panel during infusion, make safer.
10 For avoid misoperation, press 'POWER' for 3 seconds to close the pump.e the pump.
11. Able to set flow rate by single digit, tens digit and hundreds digit separately, not need to increase from single digit.
12. KVO (Keep Vein Open) function. After finish setting infusion amount, for prevent to form thrombus, keep to infusion at the lowest rate 0.1ml/h.
13. Bolus (Quick Infuse) function.
14. Purge (Evacuate Bubble) function.
15. Press 'mL', real-time display infused volume.sed volume.
16. The bright & large LED screen could be clear seen far from 10 meters.ters.ters.
17. The battery can be used continuously for 5 hours after full charged.
18. Equip with special adjustable-pitch fixed bracket. It could adjust the pump on 45ºC angle or other angle for easy watching.ching.ching.
19. The chip in syringe pump is be processed by ourselves on SMT machine production line instead of by manual work, as weld every point by hand.
20. CPU control, stable function, high reliability.
Work Term
| Temperature | -5ºC~+40ºC~+40ºCrdm;C~+40ºC |
| Relative humidity | ≤80%RH0%RH0%RH |
| Power supply | AC220V±22V,50HZ±1HZ50HZ±1HZsmn;1HZ50HZ±1HZ |
| Built-in battery | 12V±1.5V,the battery can be used for 2 hours when fully charged.charged.charged. |
| Atmospheric pressure | 860hPa~1060hPa |
| Storage condition | temperature -40ºC~55ºCC~55ºCrdm;CC~55ºC |
Technique Parameter:
| Size (mm) | 320(L)x145(w)x120(H) |
| Weight | about 3KG |
| Consume power | ≤10VA10VA10VA |
| Frequency | 50HZ±1HZusmn;1HZusmn;1HZ |
| Usable injector (one-off) size | 10ml, 20ml, 30ml, 50ml |
| Flow rate option | 0.1ml/h~199.9ml/h, minimum step 0.1ml/h |
| Transfusion amount setting | 0.1ml~999.9ml,minimum step 0.1ml |
| Block pressure | 40~70kPa |
| Flow rate error | ±5%(0.1ml/h≤Flow≤50ml/h)low≤50ml/h)/h)low≤50ml/h) |
| ±3%(50ml/h≤Flow≤199.9ml/h)≤199.9ml/h)/h)≤199.9ml/h) | |
| Alarm | self-test, occlusion, near-end, completion, underpowered battery Function: injector type test, transfusion amount indication, power indication, alarm volume option, auto-alarm, KVO function |
HSP-3 Syringe Pump's Advantages
1. Our syringe pump could use all brands through calibration (default setting is Terumo), syringes including 10ml, 20ml, 30ml, 50ml.
2. Auto-recognize the syringe size: 10, 20, 30, 50ml.
3. Available for adjust alarm volume (3 levels), standby alarm delay time (1-9min), nearly finish alarm interval (0-3min).
4. Power Switching Function: When AC power is disconnected, automatically switch into battery power supply and give indication. When the AC power is connected, automatically switch into AC power working.
5. Repeat Alarm Function: If the alarm real reason is not be resolved within 2 minutes after press 'SILENCE' button, it will give alarm again to remind to resolve the problem.he problem.
6. Battery Protection Alarm: For protect battery and safety infusion, the battery power will be displayed as different levels in sound and light from nearly finish to exhausted.
7. Double confirmation function when flow rate≥300ml/h, make safer and avoid misoperation.ion.ion.
8 The data can be cleared, make safer.
9. Lock the control panel during infusion, make safer.
10 For avoid misoperation, press 'POWER' for 3 seconds to close the pump.e the pump.
11. Able to set flow rate by single digit, tens digit and hundreds digit separately, not need to increase from single digit.
12. KVO (Keep Vein Open) function. After finish setting infusion amount, for prevent to form thrombus, keep to infusion at the lowest rate 0.1ml/h.
13. Bolus (Quick Infuse) function.
14. Purge (Evacuate Bubble) function.
15. Press 'mL', real-time display infused volume.sed volume.
16. The bright & large LED screen could be clear seen far from 10 meters.ters.ters.
17. The battery can be used continuously for 5 hours after full charged.
18. Equip with special adjustable-pitch fixed bracket. It could adjust the pump on 45ºC angle or other angle for easy watching.ching.ching.
19. The chip in syringe pump is be processed by ourselves on SMT machine production line instead of by manual work, as weld every point by hand.
20. CPU control, stable function, high reliability.
