Product parameters:
Performance and features:
1. Microcomputer control, LCD display the whole process of visualization of sterilization, touch-button
2. Temperature, pressure, time, vacuum full dynamic liquid crystal display, running process status display
3. Water, pulsation vacuum, heating, sterilization, drainage exhaust, vacuum drying the entire process automatically
4. Three times of pulsating vacuum, the vacuum can reach -0.081MPa, to ensure efficient drainage dressings, Class A, Class B cavity equipment air
5. With equipment, dressings, rubber, liquid four fixed procedures, and another user-defined sterilization procedures
6. With standard PT / TT test interface, user-friendly testing
7. Sterilization after the end of a number of pulsating vacuum drying system to ensure good sterilization dry items
8. With 0.22um bacterial air filter to ensure that the air to break the vacuum sterile air, to avoid re-pollution
9. Handwheel translation type quick-opening structure, self-rising seal
10. Immersion heating tube heating, high thermal efficiency
11. Soft drinks within the circulatory system, not to discharge steam, clean and dry environment
12. The end of the sterilization buzzer to remind and automatically shut down
13. High-quality stainless steel machine, with double stainless steel mesh basket
Technical Parameters:
Technical Parameters | LS-50HV | LS-75HV |
Effective volume of sterilization chamber | 50L (φ340× 550) mm | 75L (Φ400× 600) mm |
Fixed work stress | 0.22 MPa | |
Rated operating temperature | 134Lt; 0 & gt; C | |
Maximum working pressure | 0.23 Mpa | |
Thermal uniformity | Lt;Lt; 0 & gt; C | |
Timing selection range | 1~ 99 min | |
Temperature selection range | 0~ 134Lt; 0 & gt; C | |
power / voltage | 3000W / AC220V.50Hz | 4500W / AC220V.50Hz |
Dimensions | 690X 470X 1140 (mm) | 730X 510X 1270 (mm) |
Transport volume | 760× 550X 1290 (mm) | 820× 600X 1380 (mm) |
Gross weight /net weight | 120Kg / 100Kg | 140Kg / 118Kg |
