1) Dimension

: a) 80*71.5*25mm b) 80*71.5*38mm c) 92*82.5*25mm

d) 92*82.5*38mm e) 110*90*25mm f) 120*105*25mm

g) 120*105*38mm h) 135*111*38mm i) 150*122*50mm

j) 172*162*51mm k) 200*167*60mm

2) Rated voltage: AC 110V 60HZ, AC 220V 50HZ
3) Type: ball bearing, sleeve bearing

4) Safety Approvals: CE, TUV, UL, CUL, CCC

5) Electric strength: AC 1500V for 3 sec ( (0.5mA allowable between lead wire and frame.

6) Insulation resistance: 10M ohm between lead wire and frame (DC 500V)

7) Life expectancy (ball bearing) : 50, 000hrs rain at 25 degree C relative humidity 65%+/ -20%

8) Life expectancy (sleeve bearing) : ) 30, 000hrs rain at 25 degree C relative humidity 65%+/ -20%

9) Operation temperature: -10 to 70℃

10) Storage temperature: -40 to 75℃

11) LeadWire: UL1007 (AWG18-30)

12) Protection: Motor protection and polarity protection

13) Plastic Material: Black PBT (UL 94v-0) glass filled

14) Frame: aluminumalloy Impeller: Plastic

15) Electric Strength: AC 1500V for 3 sec
