1) Dimension

: a) 51*20*15mm b) 58*30*28mm c) 60*45*15mm

d) 75*38*25mm e) 75*39.5*30mm f) 94*56.5*33mm g) 120*60*32mm

2) Rated voltage: 5V/ 12V/ 24V
3) Type: ball bearing, sleeve bearing

4) Safety Approvals: CE, TUV, UL, CUL, CCC

5) Electric strength: 1mA max at 1000VAC for 1 min between lead wire and frame.

6) Insulation resistance: 10M ohm between lead wire and frame (DC 500V)

7) Life expectancy (ball bearing) : 50, 000hrs rain at 25 degree C relative humidity 65%+/ -20%

8) Life expectancy (sleeve bearing) : ) 30, 000hrs rain at 25 degree C relative humidity 65%+/ -20%

9) Operation temperature: -10 to 70℃

10) Storage temperature: -40 to 75℃

11) LeadWire: UL1007 (AWG18-30)

12) Protection: Motor protection and polarity protection

13) Plastic Material: Black PBT (UL 94v-0) glass filled

14) Frame: Plastic Impeller: Plastic

15) Function: Function type is optional
