Air pressure, wind pressure self-help device self-rescuer

working principle

Air pressure self-help devices (also called self-rescuer air pressure), mainly for having a coal and gas outburst coal mine disaster protection. When the coal and gas outburst or highlight omen, staff can enter the self-help device Escaping the nearest General The number of self-help devices installed downhole case not less than one-third full of downhole.

Air pressure self-help device uses light absorption mask Hu conducted directly in the mouth with Hu suction, also with a stable pressure regulator, manual flow regulation, three silencers, filters, drainage, dust of six functions, but also within the scope of the spring tube freedom of movement conveying fresh air through the device, so that disaster prevention staff can be a long suction Hu easy reach safety disaster prevention, emotional stability purpose. It's commonly used mine air pressure gas pipeline, to reduce wind pressure gas pressure, muffler, flow control, water filtering and other functions, to provide fresh air for the staff. This means there is easy to install, nice, long life, low noise, clean air and health, does not affect the line of sight, people in certain Advantages activities within the scope of work, one ideal ZYJ mine air pressure self-help device.

The basic parameters of air pressure self-help device :

System supply pressure: 0.3-0.7MPa

Hu suction pressure adjustment range: 0.05-0.1MPa

Hu Haustorium gas volume range: 30-55L / min (0.3MPa)

Air supply: ground system or single-energy pumping gas supply

Silencer capacity: ≤85dB (A)

Mode of operation: a manual rapid supply

Protection methods: protective masks

Size (length X width X height): 800X370X160

Weight: 15kg

The new one hundred million coal, always in good faith, to quality of survival, to the credibility of development. Based on customers, providing customers with the highest quality products, the best quality service. We warmly welcome you to inquire!

Sales Manager: Hou Guijuan

Sales Hotline: 153765028730537-3151358

Work QQ: 1684599823

Want: yimei018

MSN E-mail:. Yimeijixiehou @ 163 com

Company Name: Jining one hundred million coal Machinery Equipment Manufacturing Co., Ltd.

Company Address: Electromechanical South Road, High-tech Zone, Jining City,
