Unilateral curved rail side dump mine car MCC3-6 Dropside tub

Side dump mine car types and manufacturers

I plant mainly produces mine material car; various tub; fixed tub; tipping bucket tub; mining flatbed; and a tub accessories; such as tricyclic chain; tub pins (connecting pin, pin), mining materials, vehicles, the Second Ring chain tub meet, meet in the spring, mining flatbed, meet seat, universal ring, mine wheels, mine Wheel, mining materials, vehicles.

Unilateral curved rail side dump mine car (hereinafter referred tub) structure type is on one side or both sides of the trunk can be opened, with mounted on the unloading point unloading ore mine curved rail to make the tub tilt lever to open the side door unloading mine, its basic structure type as shown.

Mainly used in metallurgy, mining, coal, railway, highway tunnel, concrete culvert, underground mine drift and military culverts and other projects tunneling, construction, supporting simple and efficient slag transport equipment.

Dropside tub by a tractor; winch drive; can be drilled with the drilling; claw stand rock loader and ore leavened open gate discharge systems supporting the combined loading; ore blocks of not more than 500 mm; load volume according tub ; traction lead after charging through to the operating speed of not more than 1m / sec) dedicated curved rail unloading mechanism when the wagon turned into the largest discharge angle to the horizontal, the door is also open to the maximum program then unloading carts?. It has been completed. On return, carts curved rail through the door and turn off automatically in place.

Side dump mine car dump into the form of curved rail and hydraulic for users to choose.

No.	model	Volume M³	Loading Kg	gauge	Dimensions			Wheelbase	Wheel diameter	High traction	Traction KN	Uninstall angle degree	weight Kg
No.	model	Volume M³	Loading Kg	gauge	long	wide	high	Wheelbase	Wheel diameter	High traction	Traction KN	Uninstall angle degree	weight Kg
1	MCC1.2-6	1.2	3000	600	2100	1050	1200	600	300	320	60	≥42	≤1083
2	MCC1.6-6A	1.6	4000	600	2500	1200	1300	800	350	360	60	≥42	≤1670
3	MCC2-6A	2	5000	600	3000	1250	1300	1000	400	385	60	≥42	≤1830
4	MCC2.5-6A	2.5	6250	600	3500	1250	1300	1100	400	385	60	≥42	≤1850
5	MCC3-6	3		600	3600	1350	1335	1400	350	420	60	≥42	3480

Curved rail side dump mine car series of technical parameters

Technical parameters curved rail side dump mine car

0.7M31.2M31.6M32.0M32.5M34.0M36.0M3

V (M) 0.71.21.62.02.54.06.0

Load (t) 1.753456.251015

Gauge (mm) 600600600/762600762/900762/900762/900

Wheelbase (mm) 6006008001000120020002000

Wheel Diameter (mm) 300300350/400400400350350

Traction height (mm) 320320320320320430500

Uninstall angle (degrees) 40404242454242

Tractor speed (km / h) 121212121288

Turning radius (m) 8101012121515

Form coupling bolt chain bolt chain ring ring ring bolt chain bolt chain bolt chain ring ring ring bolt chain bolt chain ring

Dimensions Length (mm) 165019002750/25003000365036505000

Width (mm) 980105012001250125015001800

Height (mm) 1050120013001300130015861675

Weight (kg) 750100016631830250538504900
