Fixed tub MGC1.1-6 coal safety certificate

Professional tub manufacturers, coal safety certificate is complete!

Fixed trunk tub fixed tub Type and basic parameters, please call 15376502873

Fixed trunk tub structural type carriages fixed to the frame, the basic structure of the type shown in Figure tub.

Fixed van tub

1.8T fixed tub technical parameters:

Fixed tub models MGC1.1-6

Volume 1.1m3

Gauge 600mm

Wheelbase 550mm

Wheel diameter 300mm

Load 1.8T

Weight 610kg

Dimensions 2000 * 880 * 1150mm

Fixed tub consists of: fixed mine car by the car, frame, wheel, ¢ 40mm connection bolt and other components.

1. carriages: the box plate; welding mouth from side angle, etc; cover

2. Frame: the channel, tipping bucket, tub - angles, meet, axis card welding components.

3. wheel: the wheel; shaft; bearings and other components

The link plug: There are 40mm high quality carbon steel bar, hand ring welded components.

Tub accessories: mine wheels, mine wheels right, meet tub polyurethane, rubber tub meet, meet in the spring, anti-off circle, three-ring chain, universal ring, mine car pin, tub rails like.

Establish a corporate image, enhance their visibility and create corporate brand, we in the principle of "all the pursuit of quality, customer satisfaction for the purpose 'is to provide customers with the best price, the most attentive service, the most reliable product quality.

I plant mainly produces mine material car; various tub; fixed tub; tipping bucket tub; mining flatbed; and a tub accessories; such as tricyclic chain; tub pins (connecting pin, pin), mining materials, vehicles, the Second Ring chain tub meet, meet in the spring, mining flatbed, meet seat, universal ring, mine wheels, mine Wheel, mining materials, vehicles.
