Vertical shaft hammer crusher

Vertical shaft hammer crusher (sand making machine), for the new crushing equipment, with a compact, high crushing efficiency, easy maintenance, etc., suitable for crushing all kinds of ores and rocks.
Main technical performance:
Model: CPL1000 (ZSL1000) rotor diameter (mm): 900
Working chamber height (mm): 856 Max feed size (mm): 25
The particle size (mm): 5 ((5) spindle speed (rpm) 520 (753)
Production capacity (t / h): 21-28 (10-20) motor Model: Y280S-6
Motor power (kw): 45 motor speed (rpm): 980
Motor Weight (kg): 4345 (4050) Dimensions (L * W * H) (mm): 2714 * 1500 * 1500

Model: CPL1250 (ZSL1250) rotor diameter (mm): 1140
Working chamber height (mm): 865 Max feed size (mm): 70
The particle size (mm): 8 ((5) spindle speed (rpm) 420
Production capacity (t / h): 40-50 (15-36) motor Model: Y315M1-8
Motor power (kw): 75 motor speed (rpm): 740
Motor Weight (kg): 6800 Dimensions (L * W * H) (mm): 3180 * 1600 * 1948

Model: CPL1500 (ZSL1500) rotor diameter (mm): 1380
Working chamber height (mm): 865 Max feed size (mm): 30
The particle size (mm): 10 ((5) spindle speed (rpm) 590
Production capacity (t / h): 60-70 (25-40) motor Model: Y315M2-6
Motor power (kw): 110 motor speed (rpm): 990
Motor Weight (kg): 9370 Dimensions (L * W * H) (mm): 3624 * 1900 * 2103

The new one hundred million coal, always in good faith, to quality of survival, to the credibility of development. Based on customers, providing customers with the highest quality products, the best quality service. We warmly welcome you to inquire!
