Shandong Machinery Factory machine unburned unburned press hollow brick machinery
bargain
add to cartJF-QM6-15 multifunction shock compression tiles molding machine
(A) the main technical parameters:
No. | project | parameter |
1 | Shock shock force | 78KN |
2 | Vibration frequency | 5000 times / minute |
3 | amplitude | 15mm |
4 | noise | 95db (A) |
5 | Vibration time | 6 seconds / times |
6 | Dimensions | 4000 * 2300 * 2600 (mm) |
7 | Capacity | 26.4KW |
8 | Total Weight | 8 tons |
9 | Maximum pressure | 10 tons |
10 | Pallet size | 850 * 30 (mm) |
11 | Operation number | 6 |
12 | Land area | ≥5000㎡ |
(B) for brick and yield:
Product specification L * W * H (mm) | Forming Number | Production per hour | Production cycle |
Porous brick 240 * 115 * 90 | 18 | 4620 | 15 seconds / times |
Standard bricks 240 * 115 * 53 | 36 | 8640 | 15 seconds / times |
(Hollow brick 390 * 190 * 190 | 6 | 1440 | 15 seconds / times |
www.concretebrickmachine.com
QQ: 1871671868
Tel: 15122361939
Contact: Wang
Tianjin Jian Feng Hydraulic Machinery Co., Ltd.
Address: Jixian County of Tianjin Development Zone
JF-QM6-15 multifunction shock compression tiles molding machine
(A) the main technical parameters:
No. | project | parameter |
1 | Shock shock force | 78KN |
2 | Vibration frequency | 5000 times / minute |
3 | amplitude | 15mm |
4 | noise | 95db (A) |
5 | Vibration time | 6 seconds / times |
6 | Dimensions | 4000 * 2300 * 2600 (mm) |
7 | Capacity | 26.4KW |
8 | Total Weight | 8 tons |
9 | Maximum pressure | 10 tons |
10 | Pallet size | 850 * 30 (mm) |
11 | Operation number | 6 |
12 | Land area | ≥5000㎡ |
(B) for brick and yield:
Product specification L * W * H (mm) | Forming Number | Production per hour | Production cycle |
Porous brick 240 * 115 * 90 | 18 | 4620 | 15 seconds / times |
Standard bricks 240 * 115 * 53 | 36 | 8640 | 15 seconds / times |
(Hollow brick 390 * 190 * 190 | 6 | 1440 | 15 seconds / times |
QQ: 1871671868
Tel: 15122361939
Contact: Mr. Wang
Tianjin Jian Feng Hydraulic Machinery Co., Ltd.
Address: Jixian County of Tianjin Development Zone
