IP2 test probe | IEC61032 Figure 2 | Test probe B
product description:
In line with GB4706, GB2099, GB4943, GB4208IPX2, GB3883 Figure 1, IEC61032 2 test with B, IEC950 Figure 2A, IEC60884, IEC60335, GB / T16842 test with B, UL507, EN60529 Figure 1, UL1278 Figure 8.4 and other standards. For prevent finger touch or electric shock protection test test .

Basic introduction :
1, made ​​according to the corresponding provisions of GB4706.1-2005, GB2099.1-2008 and related IEC61032, UL and so on .

Technical Parameters:
1, bend refers to the diameter : 12 mm
2, curved finger length : 80mm ( three total length )
3, the baffle diameter : 50mm
4, baffle length : 100mm
5, the reference standard : GB4706.1-2005 8.1.1 strip, IEC61032: 1997 Figure 2
