Model FBZ-A FBZ-B FBZ-C

Input Power : 3N380V / 50Hz 25KVA 3N380V / 50Hz 25KVA 3N380V / 50Hz 25KVA

Welding speed 6-18m / min 6-18m / min 6-18m / min

Productivity (cpm) ≤30 ≤60 ≤60

Applicable can diameter (mm) Φ250-Φ290 φ120-φ180 φ53-φ150

Applicable can height (mm) 180-450 ≤250 ≤250

Amount of overlap (mm) 0.8-1.2 0.4-0.8 0.4-0.6

Material thickness (mm) 0.28-0.4 0.18-0.3 0.18-0.25

Copper T2 (mm) Φ1.5 Φ1.5 Φ1.5

Compressed air 900L / min 0.5Mpa 900L / min 0.5Mpa 900L / min 0.5Mpa

Cooling water ≥0.3MPa 8 ~ 10L / min ≥0.3MPa 8 ~ 10L / min ≥0.3MPa 8 ~ 10L / min

Weight (kg) 2000 1850 1850

Dimensions (mm) 2100 * 1900 * 1900 2000 * 1800 * 1600 2000 * 1800 * 1600
