Features

Superiority

Support monitor via computer and most of intelligent cellphone on the market (such as Android , Iphone cellphone

mobile software

Provide special software in the iPhone or android mobile phone

DDNS (free)

Built in free DDNS system

CMS software

multi-window mangement software

System security

Supports three-level account; password; user multi-level authority management

CPU

Operation system

Embedded Linux OS

Microcomputer processor

32Bit RSIC Embedded Processor

Network

Network interface

RJ-45 10/100Mb self-adaptable Ethernet slot

Protocol

Support TCP/ IPHTTPICMPDHCPFTPSMTPPPPoE etc.

Wireless

WIFI, 802.11 b/ g

IP mode

Dynamic IP address; static IP address; PPPOE

Online visitor

Streaming in (640 * 480) directly connected , Support 4 visitors at the same time

Streaming in (320*240) directly connected , Support 4 visitors at the same time

Streaming in (160* 120) directly connected , Support 4 visitors at the same time

Video

Compression format

Motion-JPEG

Signal system

CMOS 300000 pixel

Frame rate

1-25fps

Resolution

VGA (640*480) ,QVGA (320*240) ,QQVGA (160*120)

Image adjustment

Brightness, contrast.

WB, BLC

Auto

LUX

0.3LUX/ F1.2

SNR

) 48dB

Lens

Standard: 3.6mm SBC lens

Audio

Compression format

G. 711/ G. 726

Input

Built-in Mircophone

Output

Video output

PTZ

Motor

No

Rotation angle

No

Preset

No

PTZ Protocol

No

Nightvision

Filter switch

Can auto-switch automatically, without color cast

Nightvision

8Φ5 LED lights IR distance: 10m

Alarm

Input/ output

Motion detection/ FTP server ; email notification; HTTP

Alarm detection

Motion detection; Detection sensitivity Settings

Detection area

One

Alarm notification

IO linkage; FTP server ; email notification; HTTP

Others

Shape material

Goose egg type

environment

indoor

Power supply

5V 2A

Operating temperature

-10~50°C

Operating humidity

10%~90%RH

Dimension

Item size: 100mm x 85mm x 65mm (L*W*H)

Package size: 145mm x 145mm x 90mm ) (L*W*H)

Weight

Item weight: 128g (Note: for real products ) Package weight: 370g

Accessories

Power adapter; CD; srews ; bracket

System

System requirement

Microsoft Win98 SE/ ME/ 2000/ XP, Vista, Win7, Internet Explorer8.0.

Certification

Certificate

CE FCC ROHS ISO

patent

has been applied patents for appearance of the structure
