Description
TH4209 is formulated with a variety of additives such as extreme pressure antiwear agent and antioxidant, etc. It serves as a multiple functional additive package for universal gear oils. It works effectively to prevent gear surface from scuffing, abrasion, pitting and spalling under harsh conditions like speedy impact and high torque; and keeps rust and corrosion away from the gear surface.

Applications

Performance grade	Treating rate (m%)
CKC	1.1
CKD	1.5
GL-4	2.1
GL-5	4.2

Above treating rates are calculated by addition method. This product is applicable for the preparation of the gear oils of SAE90, 80W/ 90, 85W/ 90, 85W/ 140 blended with Group I and Group II gear oils. The qualities of GL-4 and GL-5 respectively comply with the requirements of the standards Q/ SH011-066-96 and GB13854. The qualities of the blended CKC and CKD comply with GB 5903 standard.

Characteristics

Item	Typical value	Test method
Density, kg/ m3, at 20oC	Report	ASTM D1298
Flash point (COC) ,oC	100	ASTM D92
Kinematic viscosity, mm2/s, at 100oC	6	ASTM D445
Phosphorus, mass%	0.9	ASTM D1091
Sulfur, mass%	30	ASTM D129
Nitrogen, mass%	0.3	GB/ T3228
Mechanical impurities, mass%	0.1	GB/ T511

Packing, Transportation and Storage
1, The package is packed in metal drum of 200 litres. Avoid contacting with strong oxidizer.
2, Ambient temperature for storage should not exceed 50^oC. Entering of water and impurities is strictly forbidden.
3, The packing, marking, transportation, storage and delivery acceptance should meet the requirement of SH/ T0164.

Points for Attention
1, The package is a kind of functional additive package, applied by adding with antifoam agent.
2, The recommended temperature for blending of oil is 60-65^oC.
3, The temperature of heating steam for transferring and blending should be 65-70^oC.
