It applies to various grades of raw cotton, the full opening of the cotton fiber through the machine, the may exclude contained short fiber, dust and small impurities, thereby reducing yarn faults, improve the quality of yarn .
The machine can be used for ring spinning spindles, especially for spinning spinning process, it can also be installed in the opening and picking process.
Main Specifications
Yield (kg / h) | 800 |
Machine width (mm) | 1600 |
The number of fans | 3 |
Fan type | Seraphim straight blade |
Diameter (mm) | 425 |
Speed (r / min) | 1000-2300 |
Fan exhaust volume (m3/h ) | About 400 |
Number plate valve (time / min) swing times | 60-75 |
Filter area | 25754 |
Total power (kw) | 12 |
Dimensions ( L * W * H ) (mm) | 2150*1864*2650 |
Full machine weight (kg) | About 2200 |
