Features:

1. The use of advanced direct digital frequency synthesizer (DDS) waveform generation technology; high frequency stability; good continuity;

2. high measurement accuracy for the current half sine wave and similar tests with various waveforms DC component;

3. To provide an embedded PC, intelligent monitoring system;

The full range of adjustable output voltage 0-150V, 0-300V, step away from the 0.1V;

5. Output frequency 45-120Hz (40-500 Hz optional), step away from the 0.1Hz;

6. Output current limit function;

7. With 3 sets of memory, commonly used parameters can be (voltage V; frequency F; current I) storage, easy to use when you call;

8. With RS232C communication interface, IEEE488.2 (GPIB) optional instruction execution time of less than 1ms;

9. Protected Mode: overvoltage; overcurrent; overload; short circuit; current limiting;

10. Provide RMS voltage, RMS current, active power, frequency, power factor and other readings;

11. In addition to the 100 percent load load, the regulator reaction time in less than 2ms, overload capability, instantaneous current can withstand 3 times the rated current.

With soft start (start time according to user requirements in the factory set up), especially for inductive loads, such as motor starting, transformers.

application:

Automated test system development unit best military equipment 400Hz power supply

Computer equipment test airport equipment 400Hz power OA product testing

Space Air Conditioning Equipment Testing Equipment Testing LCD computer test

Technical Parameters:
