AND220 series dedicated power line frequency inverter

(Introduction)

AND line frequency inverter for power plants, substations and high reliability requirements of the power supply to the new technology developed intelligent frequency inverter, the system uses SPWM pulse width modulation technology, IGBT module and output isolation transformer, the output inverter frequency stabilization for a regulator, filter noise, interference from power fluctuations. low distortion pure sine wave power supply with load capacity, load compatibility, DC input voltage range width and other characteristics, to meet the great demand for various electrical environments, and improve protection device to improve system stability and reliability; humanity was the LCD interface design, makes machines to communicate zero distance, inverters and between the PC can communicate via RS232 communication interface, allowing users to easily work on the terminal at any time to observe the situation, history inverter, timely inverter control.
(Features)

• Efficient IGBT inverter technology

IGBT has a good high-speed switching; the operating characteristics of high voltage and high current; voltage-type drive; only a very small control power; high efficiency (low loss and low heat), the drive circuit miniaturization, high reliability.

• Superior load characteristics:

Fully meet the transition from 0-100% load; to provide instant full-load requirements; and having to switch to bypass; and keep the output stable and reliable;

• to allow 100% unbalanced work:

• three-phase modulation independent, full-bridge inverter technology, three-phase unbalanced load 100% can be normal and reliable power supply.

• input and output using frequency isolation transformer isolation, has EMI suppression.

• using electricity standard cubicle designs.

• Colors can be based on user requirements.

• Internal installation backstop diode

DC-DC bus between the input side and connected via blocking diode prevents the DC bus voltage is higher than the DC input side of the high voltage to a DC-screen anti-irrigation, played the role of DC-screen protection.

(Technical Parameters)

Customer Case

Harbin Aviation Industry (Group) Company

PLA 5706 factory

PLA 5712 factory

PLA 5720 factory

PLA 4801 factory

PLA 4808 factory

Beijing 62320 troops

062 base

Guiyang aircraft factory

Guizhou Space Appliance Co., Ltd.

Shenyang Hangda airborne equipment company

Beijing Aircraft Maintenance and Engineering Corporation

Four Hite Group, Chengdu Aviation Instrument Factory

Taiyuan Aviation Instrument Factory, Harbin Hang new Electric Co., North Vehicle Research Institute, Ordnance Department 203 Research Institute, Southwest Institute of Technical Physics, Academy of Astronautics second section 206, the position of Aerospace Science and Industry eight thousand three hundred fifty-seven Institute, Zhengzhou twenty-seven, Xi'an Air Force Engineering Institute, Shaanxi Aircraft, Hanzhong one hundred and one into the flight, etc. 54 Shijiazhuang, Xi'an Aircraft Maintenance Engineering Co., Ltd. Witt Tianjin Institute of Civil Aviation, the state-owned public machinery factory.
