SVC single-phase high-performance automatic AC regulated power supply

SVC single-phase high-performance automatic AC regulated power supply

bargain

add to cart
Input voltage: 0 (v) Waveform distortion: 0 (%) Frequency voltage: 0 (%)
Output voltage: 0 (v) Load voltage: 0 (%) Circuit mode: SPWM switch
Load type: mixed load Customized processing: Yes Efficiency: 0 (%)
Range of application: home appliance manufacturing Type: AC power supply Model: AF60
Output frequency: 0 (Hz) Brand: ACSOON Product certification: CCC
Control mode: pulse-width modulation Input frequency: 0 (Hz)

SVC single-phase high-performance automatic AC regulated power supply

SVC single-phase high-performance automatic AC regulated power supply Description:

SVC single-phase high-performance automatic AC regulated power supply by contacting auto-voltage regulator, servo motor control circuits and other components, is driven by a servo motor carbon brush change the regulator coil turns ratio to the steady voltage function of a universal AC power supply. When the voltage is not stable or load power change, automatic control circuit output voltage change drive servo motors, adjust brush on the contact-auto-voltage regulator, so the output voltage is adjusted to the rated value, automatic voltage regulators. This series power supplies with a wide voltage range, high precision, the output waveform distortion, high efficiency, can adapt to a variety of loads. This series is widely used in computers and their peripheral location, medical device, telecommunications broadcasting equipment, air conditioning, industrial production line of electrical equipment, such as voltage regulators, and widely used in household appliances products regulated and protected.

SVC single-phase high-performance automatic AC regulated power supply main technical parameters:

Output power

Single-phase 0.5KVA-50KVA

Input voltage

Single-phase 220V ± 20%

Output voltage

Single phase 220V ± 3% (5KVA 110V output)

Response time

1.5s (input voltage change (10%)

Efficiency

≥95%

Protection function

Over voltage; Flow; Lack of protection (50KVA and above)

Waveform distortion

No additional distortion

Convert function

Voltage regulator, voltage conversion (option)

Blackout since service startup

Long term unattended

Dielectric strength

≥2M

Data for reference data; Subject to change; Subject to change without notice
