110V / 60HZ / 5KVA three-phase inverter power supply is designed for the import and export of electrical products transformer voltage, frequency test power supply design and manufacturing, can provide world standard grid voltage and frequency, output voltage, frequency stepless digital adjustable waveform purity and stability, eliminate network interference, applicable to the export of electrical products voltage, frequency test; laboratory, measuring room for all kinds of sophisticated tests, and as imports 60Hz power supply device A F60 series was going to be electric power by the power conversion circuit changes. A power supply for the required voltage and frequency, its main feature is to provide a reliable pure sine wave power output, to harmonic distortion, frequency and voltage stability of the high rate. A F60 Series Power on the general load types without special requirements but taking into account the grid voltage fluctuations, can be adapted to resistive, inductive, capacitive, rectification and mixed load. Technical parameters given sample is rated state, under conditions of resistive load test at rated conditions, supply long run. load current crest factor, short-time overload and other factors, select the power frequency is appropriate margin should be left mixed load: frequency drift, waveform distortion, noise interference, harmonic interference, Jianbo pulse, voltage surges, brownouts , voltage sag.
110V / 60HZ / 5KVA three-phase inverter power supply Product Features:

1. The use of separate (stand-alone), output isolation power transformer structure, three-phase single-phase desirable use

2. The high-precision frequency stabilization; rapid adjustment knob voltage; frequency; available with load directly regulate online

3. The three-phase active power; frequency; high precision; strong anti-interference ability

The transient response speed, 100% load / unload, the regulator within 2ms response time

5. No radiation interference; containing a small harmonic components; and after special treatment; no interference

6. Unique instantaneous value control; small waveform distortion; high control accuracy

7. High efficiency up to 85%; wide loads; may be inductive; capacitive; resistive load

8. Provide world standard grid voltage; frequency; simulation tests of various electrical products

9. Output voltage: high-grade phase voltage 0 ~ 300V (line voltage of 0 to 520) continuously adjustable, low phase voltage 0 ~ 150V (line

Voltage 0 ~ 260V) continuously adjustable voltage can simulate the world

10. The independent electrical parameters of table show actual real-time measurement: Output frequency; output voltage; output power and; Output Current

Load power factor

11. Mitsubishi IGBT, Mitsubishi driver module; ruby; Suzuki import filter capacitor

(110V / 60HZ / 5KVA three-phase inverter power source performance standards)

(GB7260-87 uninterruptible power supply) (Q / 01AK001-2005 programmable frequency voltage power supply) (GJB181A-2003 aircraft power characteristics) (GJB572-88 aircraft ground power supply characteristics and general requirements)

(110V / 60HZ / 5KVA three-phase inverter power supply technology parameters)
