Security CCTV Sharp CCD 420TVL 256 Preset 27x Optical Zoom 3.2~86.4mm Zoom lens Outdoor IR PTZ Dome Camera

Security CCTV Sharp CCD 420TVL 256 Preset 27x Optical Zoom 3.2~86.4mm Zoom lens Outdoor IR PTZ Dome Camera

360 USD

add to cart

Item specifics

Place of Origin:
Guangdong China (Mainland)
Technology:
Pan / Tilt / Zoom
Type:
Video Camera
Sensor Brand:
Sharp
Sensor:
CCD
Special Features:
Waterproof / Weatherproof
Style:
Hidden Camera
Model Number:
WI-JF39

Product Description

Features

  • 27x optical zoom camera, color to B/ W , with IR-CUT switch, realize IR lamp control and zoom camera IR CUT switch synchronization, reach to perfect IR night effect.
  • Double Case protect Camera device, continuing work in temperature lower than 50 degree C.
  • Use high quality components, high minute subset into TV, long life Conductive slip ring, High-quality Belts, Stable operation, high reliability.
  • Adopted domestic the most advanced zoom and optics sync way control IR lamp, in effect solve electric torch domino effect, original creation intelligent control IR lamp on and off, utilize IR light source in reason;
  • Design special camera, IR lamp sub-depot separate system, no sphere case glisten, fogging malady.
  • Constant voltage constant current circuit design, ensure IR lamp work in long life.
  • Low Power Consumption.
  • Optional temperature control system, suitable for working in high or low temperature environment. High-technica, beautiful and firm Structure.
  • Triple lightning protection technology, effectively raising the speed dome mine and anti-jamming capability.

Specifications:

Image sensor:

1/4 inch sharp CCD

Signal model:

PAL/ NTSC

Horizontal resolution:

Color: 420TVL B/ W: 600 TVL

Effective pixel:

582 (Horizontal) x 512 (Vertical)

Minimum illumination:

0LUX (with IR) , Color to B/ W, IR SENSOR

S/ N ratio:

) =50dB (Enhanced)

Backlight compensation:

On/ Off

White balance:

Auto

Electronic shutter:

1/50 to 1/12000 seconds

Focus length:

3.2 to 86.4mm

Optical focus:

27x

Focus:

Auto/ manual, take high-performance DSP to realize complete digit and ultra-high speed focus function

Presets:

256

Patrol track:

4groups, each can record 100 actions

Cruise track:

Total 30 presets can join cruise, can setting the presets residence time

Other scans:

Support Horizontal scan, deuce area scan, scan random

Rotation range:

Horizontal and Vertical Min 0.01 degree, Max 200 degree/ S

Communications:

RS-485, PELCO D, PELCO P

OSD:

Yes

Temperature control:

Built-in

Intelligent IR lamps:

50m, auto-switch the IR distance according to the focus of camera or force to turn on/ off the IR lamps through software

Power supply:

DC12V/ 3A

Material:

Aluminum shell, waterproof IP66

Work environment:

-20 degree C to +50 degree C (select temperature control accessories) ,(95%RH

Item Includes:

  • 1 x 1/4 Sharp CCD 420TVL 27x PTZ Camera
  • 1 x Power Adapter
  • 1 x Bracket

Packaging Details

Unit Type:
piece
Package Weight:
5.000kg (11.02lb.)
Package Size:
45cm x 33cm x 33cm (17.72in x 12.99in x 12.99in)
