Description:

M-JPEG compression format, support 2 way audio, WiFi, built-in Pan/ Tilt and IR lights, mobile phone view, provide alarm in and out interface, support UPNP and PPPOE, motion detection, email, FTP alarm etc.

Specification:

Image Capture:

• Sensor: 1/4 inch CMOS sensor

• Total if pixel: 300k

• Minimun illumination: IR light on, 0Lux

• Lens: f=4.5mm, F=2, Fixed Iris

Pan/ Tilt:

• Pan Coverage: 350 degree

• Tilt Coverage: 100 degree

Assistant:

• Lighting Control: Auto

• Lighting: 8PCS 850nm infrared lights, 5m distant

Video and Audio:

• Compression: M-JPEG

• Bitrate: 128kbs-5Mbps

• Frame rate: 30FPS

• Image Rotation: Mirrior/ Up-side down

• Audio Compression: ADPCM

Network:

• Basic Protocol: TCP/ IP, UDP/ IP, HTTP, SMTP, FTP, DHCP, DDNS, UPNP, NTP, PPPOE

• Other Protocol: 802.11b/ g

Other Features:

• Video control: support

• Dual way audio: support

• Memory: Snap or video into SD card

• Browser SD card: View or download form network

• Motion Detection: yes

• Triggered Action: E-mail/ FTP/ extermal alarm/ send message to alarm server

• User Setting: three levels

• Date/ Time Setting: support

• DDNS: A free DDNS provided by manufacturer

Hardware Interface:

• Ethernet: 10Base-T/ 100Base-TX

• Alarm in: 1Way

• Alarm out: 1Way

• Audio in: Internal mic x 1, audio input interace x 1

• Audio out: audio output interface x 1

SoftWare (PC Side) :

• Power: DC 5V

• Power Consumption: (6W

• Operating Temp.: 0 degree C to 45 degree C

• Operating Humidity: 10% to 80% non-condensing

• OS Support: Microsoft Windows 90/2000/ XP/ Vista/ Win7

• Browser: IE6.0 and Above or Compatible Browser, Safari/ Firefox/ MAC.

• Applocation Software: IPCMonitor.exe

Features:

• The video is compressed by M-JPEG.

• VGA/ QVGA / QQVGA resolutions optional .

• Built-in microphone, support external audio signal.

• Built-in Pan/ Tilt, horizontally 350 degree, vertically 100degree.

• Support 802.11b/ g protocol, can build up wireless monitoring.

• Supports UPNP, port forwarding automatically on the router.

• Built-in web server, support video view and parameter settings by browser.

• Motion detection and alarm pin can be connected to external sensors to detect environmental situation.

• Alarming record by email, FTP server.

• Infrared LED for night vision covers 5m area.

• Support three level of user authority.

• Manufacturer Device ID, DDNS at the bottom of each IP Camera.

• Manufacturer provides free Central Management software, support Multi-view, record and play , etc.

• Support several browsers, IE, Firefox, Safari and Opera etc.

Item Includes:

• 1 x Wireless IP Network Camera
