Description:

It adopts H. 264 Main Profile@ Level 3.0 compression format, support 2 way audio, Wifi, SD Slot (32GB) , and mobile phone view, built-in Pan/ Tilt and IR, alarm in and out interface, support UPNP, motion detection, email alarm, etc. It is the real all in one ip camera.

Specification:

Image Capture:

• Sensor: 1/4 inch CMOS sensor

• Total if pixel: 300k

• Minimun illumination: IR light on, 0Lux

• Lens: f=4.5mm, F=2, Fixed Iris

Pan/ Tilt:

• Pan Coverage: 350 degree

• Tilt Coverage: 100 degree

• Preset Number: 1

Assistant:

• Lighting Control: Auto/ Manual control

• Lighting: 8PCS 850nm infrared lights, 5m distant

Video and Audio:

• Compression: H. 264

• Bitrate: 128kbs-2.048Mbps

• Frame rate: 30FPS

• Image Rotation: Mirrior/ Up-side down

• Audio Compression: G. 711

Network:

• Basic Protocol: TCP/ IP, UDP/ IP, HTTP, SMTP, FTP, DHCP, DDNS, UPNP, NTP

• Other Protocol: 802.11b/ g

Other Features:

• Mobile Phone View: M-JEPG and H. 264 dual streaming, M-JPEG Streaming sent to mobile phone

• Video control: support

• Dual way audio: support

• Memory: Snap or video into SD card

• Browser SD card: View or download form network

• Motion Detection: yes (4 zone detection)

• Triggered Action: E-mail/ FTP/ SD storage/ extermal alarm/ send message to alarm server

• User Setting: three levels

• Date/ Time Setting: support

• DDNS: A free DDNS provided by manufacturer

Hardware Interface:

• Ethernet: 10Base-T/ 100Base-TX

• Momory: SD card

• Alarm in: 1Way

• Alarm out: 1Way

• Audio in: Internal mic x 1, audio input interace x 1

• Audio out: audio output interface x 1

SoftWare (PC Side) :

• OS Support: Microsoft Windows 90/2000/ XP/ Vista/ WIN7

• Browser: IE6.0 and Above or Compatible Browser, Safari/ Firefox/ MAC.

• Applocation Software: IPCMonitor.exe

Features:

• 32-bits RISC processor and special video encoder which can be up to 300000 pixels encoding performance.

• Support H. 264 Main Profile@Level3.0 compression format, bit rate is smaller, and the image is more clear. It is more convenient for transferring through Internet and save more storage space.

• VGA/ QVGA/ QQVGA resolution optional. User can change some specification according to their demands to satisfy his own visual prefer.

• Support mobile phone watching.

• Support external microphone or line-in audio input signal to send out the live sound.

• It was equipped with pan/ tilt function, horizontally 350 degree and vertically 100degree. Its outlook is smart, easy and convenient to install in many sites.

• Built-in web server, support video view and parameter settings by browser; use one port to send all the data, it facilitates network setting.

• Support 802.11b/ g protocol, can build-in wireless monitoring.

• Supports UPNP, port forwarding automatically on the router.

• Motion detection and alarm pin can be connected to external sensors to detect environmental situation.

• Alarming record can be stored by email, FTP server. External alarm can be open when detecting unusuality. It also sends alarm info to the alarm server.

• Infrared LED for night vision covers 5m area, to realize 24 hours monitoring..

• Support three level of user authority.

• Manufacture attached a label at the bottom of each IP Camera, it include Device ID, DDNS. When IP Camera is connected to the internet, this URL can be used to visit the device.

• Manufacturer provides free software, support Multi-view, Long time recording, video replay etc.

Item Includes:

• 1 x 1/4 inch CMOS PTZ IR Camera
