Working Principle:
INS-HAS03 security alarm system, including alarm main unit, detector (PIR detector and wireless door detector can be chosen) and wireless remote control. When the sensor detect something in break, Immediately to transmit the wireless password of invasion signal to the alarm host password, after the main unit receive alarm signal, it will open high dB field alarm system at once, the panel shows zone and alarm type. Clearly shows that the position of the invaders, meanwhile, alarm host through the Network dialer rotary to the telephone number which user setting, and play the recorded voice. After receiving the call, user can do a series of remote control operation according to requirement.
INS-HAS03 security alarm system, it adopts high technology microcomputer-control system, its distance of detection is far and fashionable sculpt, Many units of alarm system use border upon, they will not disturb each other. When the host power-cut, DC power can be used, will be more economical and convenient

Range of application
House, building, courtyard, factory, garage, office, finance room, market, etc.

Main function

• It has 100 wireless zone alarm
• 6 standard wired zone
• 2 standard outlet
• Big screen with LCD
• Voice control
• With keyboard, and cover protected
• Checking arm, disarm, alarm issue, etc
• With 2 grade auto, disarm setting
• Connected with Contact ID
• Learning coding
• With outstanding password, engine password, user password monitor, convenient to user operation and engine monitor
• Auto-dialing 6 group telephone number which pre-setting
• With the function which can get the first line when alarm
• High technology and performance

Specification:

The Main
Power supply: AC 220V, DC 8.4V (7ktsAAA rechargeable Ni-MH battery)
Electric current in static state: (15mA
Alarm sound level: 100dB
Zone display: ) 100 zones

Wireless PIR detector
Detect distance: 5-10m
Power: DC 9V
Electric current is static state: (60μA

Emission frequency: 315MHz
Wireless emission distance: ) 500m (in the open air)
Temperature: -30 to 42 degree C

Wireless door sensor

Power: DC 12V, with 12V/ 23A battery
Power consumption in static state: (5μA
Emission frequency: 315MHz
Wireless control distance: ) 100m (in the open air)

Wireless remote control
Wireless emission distance: ) 50m (in the open air)
Power: DC 12V, with 12V/ 23A battery
Emission frequency: 315MHz

Item Includes:

• 1 x Home Security Inteligent Auto-dialing Wireless Alarm
• 1 x Wireless PIR detector
• 2 x Remote controller
• 1 x Magnetic Door Contact
• 1 x Antenna
