Quick Overview
2.4GHz Security Wireless System 4 Channel 4Pcs 380TV Lines 24 IR LED 15m Night Vision Range
Details
| Description: |
This is a set of clear and Remote Wireless supervision system. The appearance of the Receiver is beautiful and the Channels of the two Cameras can be changed by hand or automatically. The Camera has the function of backlight compensation, automatic white balance and so on, it has 24 IR LED, when the illumination is below 2 ~ 4 Lux, the Infrared will open automatically and can reach the best night vision effect. The supervised picture is clear and the color is bright. It is suitable for the surveillance of residence area, office, supermarket, hotel, warehouse, hospital, etc.
|
| Specification: |
| Transmission Frequency: | ISM 2.414 ~ 2.468 GHz | | Transmission Power: | 10mW/ CE; 2mW/ FCC | | Unobstructed Effective Range: | 100m (Minimum) | | Modulation Mode: | FM | | Operating Temperature: | -10 ~ +50 (Degree C) / +14~ +122 (Degree F) | | Storage Temperature: | -20 ~ +60 (Degree C) / -4 ~ +140 (Degree F) | | Operating Humidity: | ≥85%RH |
|
| Camera: |
| Imaging Sensor Type: | 1/3 Inch OV Image Sensor Chip | | Picture Total Pixels: | PAL: 628 x 582 Pixels; NTSC: 510 x 492 Pixels | | Horizontal Resolution: | 380 TV Lines | | View Angle: | PAL: 50; NTSC: 60 | | Minimum Illumination: | 1 Lux | | Night Vision Range: | 15m | | IR LEDs: | 24pcs LEDs Infrared | | Bandwidth: | 25M | | Angular Field of View: | 45° (F=6mm) | | Power Supply: | DC +5V |
|
| Receiver: |
| Antenna | 50 ohm SMA | | Receiving Sensitivity: | ) =-85dBm | | Video Output Signal Level: | 1.1Vp-p ~ 0.2Vp-p @75 ohm, S/ N ) 38dM | | Audio Output Signal Level: | 3.0Vp-p ~ 1Vp-p @600 ohm | | Power Supply: | DC +5V |
|
| Features: |
Infra-red LEDs for night-time vision, Effective night vision range: 15m. 380TV lines clear picture display. 4channel real-time wireless receiver, Alloyed shell, Antenna can be change by yourself. Built-in microphone for Audio monitoring. Minimum 100m transmission distance without block.
|
| Package List: |
4 x 2.4GHz, 1/3 inch Omn Vision Chip, 380TV Lines, 24 LED Infrared Day&Night Security cctv Wireless CMOS Color Camera
1 x 2.4GHz, 4-channel Real-time Wireless Receiver
4 x Adaptor for Camera
1 x Adaptor for Receiver
4 x AV Cable
1 x Remote Controller |
