15.6 Inch Touch LCD Monitor 8CH H.264 Standalone Network CCTV DVR Kit

15.6 Inch Touch LCD Monitor 8CH H.264 Standalone Network CCTV DVR Kit

429.99 USD

add to cart

Quick Overview

8CH Network support mobile phone DVR , 15.6 TFT LCD screen, H. 264 compression, support D1, Support Network CMS , High resolution VGA output, Support mobile surveillance, Remote power supply for 4 channel cameras

Details

Introduce: This DVR is 4channel CIF resolution digital video recorder. It has local recording, playback, support treble code remote network surveillance, data backup, parameter setting, motion detection, I/ O alarm setting, PTZ and USB mouse. Applied in large surveillance area such as bank, supermarlet, gas station, and so on. Features: Advanced Linux; H. 264 compression USB mouse control; PTZ and network function; English&Chinese Multi-Language is selectable; Touch Monitor; Support mobile surveillance; Support network center management system (CMS) ; Remote power supply for 4 channel cameras;

Specificatons:

  • Operation System: Embeded Linux

  • Compression: H. 264

  • Audio Compression: ADPCM

  • Video Code Rate: CIF: 384512768/ Kbps
    HD1: 5127681024/ Kbps
    D1: 89610241280/ Kbps

  • VideoInkput/ Output: 8 channels BNC input/ 1 channel BNC output

  • Audio Input/ Output: 8 channels RCA input/ 1 channel RCA output

  • Display Resolution: NTSC: 240 fps (8x30fps)
    PAL: 200fps (8x25fps)

  • Rescord Frame Rate: NTSC: 120fps (8x30fps)
    PAL: 100fps (8x25fps)

  • Record Model: Mannul, Schedule, Motion, Detection Alarm Trigger (option)

  • Image Quality: CIF/ HD1/ D1 selectable

  • Record Resolution: NTSC: 704x480 (DI) ,704X240 (HD1) ,352X240 (CIF)
    PAL: 704X576 (D1) ,704X288 (HD1) ,352X288 (CIF)

  • Playback Mode: 1/4/8 channel

  • Search Mode: By time / By event/ By channel

  • HDD: Support large-capacity of SATA Hard Disk (The Item Doesn't Contain Hard Disk)

  • Alarm INput/ Output: 8 channel input/ 1 channel output

  • Internet: IE/ PPPOE/ DDNS

  • Remote Control: Yes

  • USB Mouse Control: Yes

  • USB Port: Support USB 2.0

  • PTZ Control: Yes

  • Language Support: Chinese, English, Spanish, Polish, Portuguese, German, Russian, Turkish, Thai Language.

  • TFT Monitor: 15.6'TFT

  • VGA Support: 800x6001021x7681280x10241366x7681440x900 resolution

  • Video Display: 1/4/9 channels display

  • Software Upgrate: USB/ IE

  • Mobile Surveillance: Support Symbian s60 v3.0, Mobile Pocket PC mobile Phone OS, Support Samsung, Nokia, Blackberry, Dopod, SonyERICSSON, Iphone Etc.

  • Power Supply: DC12V/ 3A

  • Remote Power Supply: No

  • Working Temperature: -10~+50℃

  • Working Humidity: 10%~90%

  • G.W/ N.W: 5.8KG/ 4.3KG

  • Meas (L*W*H) : 385x345x90mm

Item Include

  • 1 X 8CH H2.64 Network support mobile phone DVR with 15.6 screen

  • 1 X USB Mouse

  • 1 X Remote

  • 1 X Power adapter

  • (The Item Doesn't Contain Hard Disk)
