AVTECH CCTV Surveillance Security 1\3 Inch H.R. Color CCD Image Sensor 520TVL 3.6mm Lens Digital IR Camera

67.99-72.99 USD

Quick Overview

AVTECH CCTV Surveillance Security 1/3 Inch H. R. Color CCD Image Sensor 520TVL 3.6mm Lens Digital IR Camera

Details

Introduction:

AVTECH 1/3 Inch H. R. Color CCD image sensor, this regular camera possesses satisfactory minimum illumination to provide clear and sharp images for your surveillance system. 520TV lines Resolution, 21 units IR LED Digital Color CCD IR Camera. ( We only offer PAL standard)

Specification:

Pick up Element:		1/3 Inch H. R. Color CCD Image Sensor
Number of Pixel:		PAL: 753 (H) x 582 (V)
Resolution:		520TV lines
Minimum illumination:		0.1 Lux / F2.0, 0 Lux (IR ON)
IR LED:		21 units
Effective Range:		Up to 15 Meters
S/ N Ratio:		More than 48dB (AGC off)
Electronic Shutter:		1/60 (1/50) to 1/100000 sec.
Lens Mount:		f3.6mm / F2.0
Lens Angle:		92.6°
White Balance:		ATW
Video Output:		1.0 Vp-p composite, 75Ω
Power Source (10%) :		DC12V
Current Consumption (10%) :		70mA (IR OFF) , 270mA (IR ON)
IP Rating:		IP67

Features:

1. 1/3 Inch H. R. color CCD image sensor
2. High resolution for clearer and sharper images of 520TVL
3. Low light sensitivity of 0.1 Lux / F2.0, 0 Lux (IR ON)
4. Day and night features for 24-hour surveillance
5. Excellent image quality
6. Auto Electronic Shutter built-in
7. Signal-to-noise ration of 48dB
8. IP67 standard approved outdoor housing
9. IR LED effective range reaches up to 15 meters.

Item Include:

1 x AVTECH 1/3 Inch H. R. Color CCD Image Sensor 520TVL 3.6mm Lens Digital IR Camera
1 x Bracket
