Supply FT-300 powder resistivity tester, carbon powder resistance tester, resistance tester

1 CNY (0.15USD)

Brand: Ricoeur Albert Instrument

Detailed description:

The company operating the FT-300 powder resistivity tester, carbon powder is low, quality assurance, welcome to consult the discussion.

FT-300 powder resistivity tester

Powder resistivity tester

This instrument applies to Carbon Plant, coking plants, petrochemical plants, metallurgy plants, universities, research department, is an important tool for testing and analysis of powder sample quality.

Main Specifications

1. Measurement Range: 0.2Ω-cm (ie 2KΩ * mm² / m)

Resolution: 0.1mΩ-cm

2. Measure the voltage ranges: 10mV error of ± 0.3% of reading ± 2 word

Resolution: 5μV

3. The amount of electric current: 0-100mA continuously adjustable, error ± 0.3 reading + word

4. Sample size: 40 mesh or less than -60 mesh (standard screen)

5. The sample container: cavity Ф16.30 ± 0.1mm

6. The sample height: 16mm ± 0.5mm

Measurement error: ± 0.1mm

7. Sampling pressure: 4 M Pa ± 0.05 MPa (40Kg / cm² ± 0.5 Kg / cm²)

Pressure Range: 5 M Pa 0-5 M Pa adjustable

8: Digital display resistance, resistivity, pressure units, the decimal point is automatically displayed

9. Power: 220 ± 10% 50HZ-60HZ Power consumption (60W

10. Dimensions: 440mm * 139mm * 360mm

FT-301 powder resistivity tester
