Conductor resistance tester, micro-ohm meter, milliohm meter, low resistance tester

Conductor resistance tester, micro-ohm meter, milliohm meter, low resistance tester

bargain

add to cart
Detailed description:
Custom processing: Measuring range: 1 (MΩ)
Type: Digital Resistance measuring instruments Power: 1
Weight: 1 (kg) Size: 1
Repeat error: 1 Accuracy: 1
Relative Humidity: 1 Test voltage: 1 (V)
Calibration cycle: 1 Custom processing:
Measuring range: Types of:
power supply: weight:
size: Repeat error:
Accuracy: Relative humidity:
Test voltage: Calibration cycle:

DC double bridge / conductor resistance fixture

QJ-57 DC arms bridge

QJ-57 DC arms bridge

QJ-57 DC arms bridge

Scope: For laboratory, workshop production line or field site, high-precision measurement of currents and low resistance values.

1) The metal rod, sheet metal or wire and cable, wire and other measuring resistivity.

2) the quality of the current staking bus, metal shell and other tests.

3) The low resistance standards, a large current shunt, power type resistor calibration and adjustment like.

4) switches, electrical contact resistance was measured.

5) The various types of motors, transformers, winding DC resistance measurement and temperature testing.

QJ-57 DC arms bridge

The main parameters:

1) limit the total effective drive: 0 ~ 1111.1Ω minimum resolution: 0.01μΩ

2) seven effective range of magnification: x10, x10, x10, x1, x10, x10, x10

3) Accuracy: 0.05%

LX-9853 Universal conductor resistance fixture (formerly LX-8853)

LX-9853 Universal conductor resistance fixture Scope: The fixture with the conductor resistance tester or DC bridge supporting the use of arms for the detection conductor resistance.

The fixture has a potential fixture and current clamps, to ensure the accuracy of the conductor current measurement resistor. LX-9853 Universal conductor resistance fixture

Note: Specific parameters, please keep in touch with us, as well as related products.

2511/2512 / 2512B Intelligent DC low resistance tester Conductor Resistance Tester / Microhmmeter / milliohm meter / low resistance tester + conductor resistance clamp / wire and cable resistance tester / contact resistance tester / digital resistance meter

DC Resistance Tester / resistivity tester

2511/2512 / 2512B Intelligent DC low resistance tester + LX-9853 Universal conductor resistance fixture

2511/2512 / 2512B DC low resistance tester Features: 5 LED display, good stability and minimum resolution:. 1μΩ
Direct reading and percentage error display, the super, super, qualified sorting and sound alarm function
RS-232C interface and provides HANDLER interface (optional) 2511/2512 / 2512B DC low resistance tester

model

2512

2511

2512B

Basic accuracy

0.05%

0.1%

Display range

0.001 mΩ - 2.0000 MΩ

0.01 mΩ - 200.00 kΩ

0.001 mΩ - 20.000 kΩ

Test current

1uA-1A 7 files

10uA-100mA total of 5 files

100uA-1A total of 5 files

Range

20mΩ-2MΩ total of 9 Range

200mΩ-200kΩ total of seven ranges

20mΩ-20kΩ total of seven ranges

The highest resolution

1uΩ

10uΩ

1uΩ

Measurement speed

4 times / second, 12 times / sec.

Range mode

Auto, keeping

Clear Function

Short circuit

Test terminal

5 end

display method

Direct reading, Δ%

Sorting function

Ultra, ultra, qualified

Interface (optional)

HANDLER, RS232

no

2511/2512 / 2512B Intelligent DC low resistance tester operating video

http: //www.tudou.com/ programs / view / 7CbEregfw_o /

LX-9853 Universal conductor resistance fixture (formerly LX-8853)

Scope: The fixture with the conductor resistance tester or DC bridge supporting the use of arms for the detection conductor resistance.

The fixture has a potential fixture and current clamps, to ensure the accuracy of the conductor current measurement resistor.

Note: Specific parameters, please keep in touch with us, as well as related products.
