Straight endoscopy, endoscopic professional manufacturers pipeline

88 CNY (12.82USD)

The amount of wear: 1	Crashworthiness strength: 0.6-2.5 (MPa)	Pipe thickness: 3-5 (mm)
Friction coefficient: 0.1	For fluid: Various petrochemical, pharmaceutical and other industries liquids or gases	Custom processing:
Material: A3 304 304L 316 316L glass-lined steel	Pipe diameter: DN25-500 (mm)	Model: SJ-PP
Brand: Beijing Jing Chen	Operating temperature range: -40 ~ 450 (℃)

I. Introduction straight endoscopy, endoscopic professional manufacturers pipeline
Endoscopy is one of the main accessory of industrial pipes means it can always observe the pipeline by the gas, liquids and other media flow reactor, monitoring of the production, the production process to avoid accidents. Often used in petroleum, chemicals, chemical, pharmaceutical and other industry production pipelines. maximum operating medium temperature 0 ~ 200 ℃ maximum working pressure is 2.5Mpa, tempered glass resistant CML temperature difference of 180 ℃.

Second, depending on the purpose and structure of the mirror
Purpose: Mirrors can be used in high temperature, corrosive, easy to poisoning, more dangerous, easily crystallized chemical tower in order to ensure its safety in production.
Structure: endoscopic mainly by the toughened borosilicate glass, flange, take over the other components.

Third, the technical parameters

Housing Material	Carbon steel, stainless steel, steel lined
Window material	Toughened borosilicate glass, quartz glass
Operating temperature	0 ℃~180℃, 0℃~300℃
Nominal	(0.6Mpa, 0.6Mpa ~ 2.5Mpa
Seal material	Nitrile rubber, Teflon
Connection Type	Threaded connection, flange connection
Abrupt changes in temperature allowed	(60 ℃
Working Pressure	0.6Mpa ~ 2.5Mpa
Flange Standard	HG20592-09 (also according to user requirements)

Manufacturing, testing standards: reference (chemical pipeline manual) and HG / T21619 ~ 21610-1986 (pressure vessel view mirror) design and manufacturing and acceptance.

Fourth, selection: straight endoscopy, endoscopic professional manufacturers pipeline
According to shape into ordinary endoscopy and endoscopy with a neck like.
Use according divided into straight endoscopy, through reducers mirrors, float mirrors, swing plate mirrors, glass sight glass and the like.
Selection must provide: nominal diameter, material, pressure rating, flange standard, operating temperature straight endoscopy, endoscopic professional manufacturers pipeline.
