Mirrors standard, mirrors the size, depending on the mirror effect, as the mirror principle

Mirrors standard, mirrors the size, depending on the mirror effect, as the mirror principle

98 CNY (14.27USD)

add to cart
The amount of wear: 1 Crashworthiness strength: 0.6-2.5 (MPa) Pipe thickness: 3-5 (mm)
Friction coefficient: 0.1 For fluid: Various petrochemical, pharmaceutical and other industries liquids or gases Custom processing:
Material: carbon steel, stainless steel, 304,316 Pipe diameter: 25-250 (mm) Model: SJ-BL
Brand: Beijing Jing Chen Operating temperature range: -40 ~ 450 (℃)

Endoscopy is one of the major industrial piping attachment means in the pipeline in petroleum, chemical, pharmaceutical, food and other industrial production device, the endoscope can be observed at any pipeline liquid, gas, steam and other media flow and reactions, play monitor production, the role of the production process to avoid the accident.

Also known as the mirror glass 'as Zhong', its greatest feature is to have the viewing surface 360 ​​℃ can be seen from all directions to the situation within the pipeline medium; low pressure, generally applicable to the low pressure line

Technical Parameters Size mm
product number SJ-BL SJ-BT caliberLH
Housing Material 20 # 304 316L glass lined steel FRPP DN25115250
Window Material Borosilicate glass Quartz glass DN32135250
Apply pressure 0 ~ 0.6MPa DN40145250
Gasket NER PTFE DN50160250
Nominal 0.6 ~ 4.0MPa 150 ~ 300LB DN65180250
Operating temperature Quartz: -30 ~ 800 O C borosilicate: -30 ~ 120 OC DN80195250
Connection Type Threaded flange welded clamp DN100215250
Flange Standard GB HG SH JB ANSI JIS DIN DN125245250
Manufacturing Standards HGJ501-86 DN150280250

Installation and Maintenance
 1, the endoscope is used to observe the liquid flow reaction apparatus, gas, steam and other media, the window glass should be kept clean and free of dust.
2, window glass damaged pieces should belong, to be handled with care when installing the sight glass.
3, glass temperature and pressure have certain limitations, see the instructions on the strict implementation of the provisions.
4, to allow urgent transition temperature (60 ℃, glass breakage due to temperature over the General Assembly.
