This product is light weight, corrosion resistance, is used in many fields, such as general water and raw water pipeline system, drainage and sewage piping systems, brine and seawater piping systems, pH and chemical solution system industries, quality has been recognized by the majority of users .
For fluid : water, air, oil, corrosive chemical liquid
Body material : UPVC
Sealing material : EPDM / PTFE

Transmission : 90º turn electric drive
Actuator material: cast aluminum
Protection: overheat protection
Action time: 5-30 / 60 seconds
Nominal pressure : 1.0Mpa
Nominal diameter : DN15-200
Protection: IP65
Fluid temperature : -15 ℃ -60 ℃ ( no freezing)
Ambient temperature : -25 ℃ -55 ℃
Installation: Installation at any angle
Power supply: standard AC220V optional DC24V, AC24V, AC110V, AC380V
Connection: internal thread, adhesives, flange
Control: switch type, feedback type, adjustable ( Smart)
