| LKV1000 P / N format converters | LKV1000 Lang strong research and production according to customer demand TV system converter, can automatically identify the signal of PAL, NTSC, NTSC-4, PAL-M, PAL-N, SECAM and other global standard input output standard digital processing after the adoption of PAL or NTSC signals. |
|
| |
Can Profile
Input signal: CVBS signal: 1.0Vpp 75 ohms matched impedance
Y signal: 1.0Vpp 75 ohms matched impedance
C signal: 0.3Vpp 75 ohms matched impedance
Output signal: CVBS signal: 1.0Vpp 75 ohms matched impedance
Y signal 1.0Vpp 75 Ohm impedance matching
C signal: 0.3Vpp 75 ohms matched impedance
Supports the input signal has: PAL, NTSC, NTSC4, PAL-M, PAL-N, SECAM
It supports output signal: PAL (4.43) 50Hz NTSC (3.58) 60Hz
Support functions: brightness, contrast, color saturation adjustment function;
OSD prompts;
Power saving function settings. |
Connection diagram
Interface Description
SOURCE - The input signal is switched to cycle between the keys, CVBS or S-VIDEO.
Menu - Menu key: brightness / contrast / color saturation cycle selection.
When BRIGHT When prompted (brightness) by + Key image brightness increase; press - The image brightness is reduced;
When CONTRAST When prompted (contrast) Press + Key to increase the image contrast; press - The image contrast is reduced;
When COLOR When prompted (color saturation) Press + Key image color saturation increase; press - The image color saturation decreases;
Press the SOURCE and - keys when the Restore Defaults |
