0.6/1kV Cold Shrink Termination and Straight Through Joint

Performance Standard: IEC60502.4; GB12706.4

Characteristics:

1. Cold shrink, which is also called Pre-expanded, is based on the characteristic of rubber that holds flexible memory. Furthermore, the flexible rubber is pre-expanded by mechanical ways during one flexible range and then inserted the plastic tubing to be fixed, While installation, Pull off the plastic tubing, the flexible rubber will shrink automatically and be wrapped onto the cable.

2. It's easy to operate while installation and meanwhile no other professional tools needed.

3. It's safe because of no fire.

4. It can make radical pressure onto the cable for long time and furthermore keep synchronous breath with cable. It has nicer performance of water-proof and sealling so that the accessory can function safely in a long time.
Order Reference

TYPE/ ORDER NUMBER	NAME	CABLE RANGE
1kV TLY 1 *25-50	TERMINATION FOR 1kV 1 CORES CABLE	25-50
1kV TLY 1 *70-120		70-120
1kV TLY 1 *150-240		150-240
1kV TLY 1 *300-400		300-400
1kV TLY 4 *25-50	TERMINATION FOR 1kV 4 CORES CABLE	25-50
1kV TLY 4 *70-120		70-120
1kV TLY 4 *150-240		150-240
1kV TLY4 *300-400		300-400
1kV TLY 5 *25-50	TERMINATION FOR 1kV 5CORES CABLE	25-50
1kV TLY 5 *70-120		70-120
1kV TLY 5 *150-240		150-240
1kV TLY 5 *300-400		300-400
1kV JLY 1 *25-50	STRAIGHT THROUGH JOINT FOR 1kV 1 CORES CABLE	25-50
1kV JLY 1*70-120		70-120
1kV JLY 1*150-240		150-240
1kV JLY1 *300-400		300-400
1kV JLY 4*25-50	STRAIGHT THROUGH JOINT FOR 1kV 4 CORES CABLE (3+1)	25-50
1kV JLY 4 *70-120		70-120
1kV JLY4 *150-240		150-240
1kV JLY 4 *300-400		300-400
1kV JLY 5 *25-50	STRAIGHT THROUGH JOINT FOR 1kV 5 CORES CABLE	25-50
1kV JLY 5 *70-120		70-120
1kV JLY 5 *150-240		150-240
1kV JLY 5 *300-400		300-400

Technical index

Item	Test Item	Standard require	Test result	Note
1kV in/ outdoor terminations and joints	1min Power frequency test	4kV 1min no flash over, no strick	4kV. 1min combination sample no flash, no strick no flash over	Pass
	Cyclic load test	5h heating, conductiontemperature 95℃, 3h colling	Subjected to 3 time Cyclic load test	Remarked by the next test
	4h Power frequency test	2.4KV 4h no flash over, no strick	2.4kV 4h Combination sample no strick, no flash over	Pass
