1, the pipe bend forming: out of roundness ≤8%; operating noise ≤80db.

2, three-axis (YBC) the velocity using 'pulse' technology acceleration and deceleration, the machine is running fast and smooth.

3, all of the data by touching the screen, input, memory capacity can store 8000 groups elbow archive data.

Data editing is done by the key off lock function to prevent data to be edited. With power and memory function, data can be permanently stored, the machine has a system recovery.

4 two feeding method: pinch, direct delivery, can be set to manual, semi-automatic operation, each setting a bend Jieke pause.

5, can be used when manual analysis test bending action, observation interference point, modify action.

6, can be set to feed each bend, back bend, turn with a three-axis motion or different actions, to avoid interference points, thereby increasing productivity.

7, the workpiece has counting function, there are three axes simultaneously zero function.

8, automatic detection of an error or machine malfunction function, and on the screen display for easy operator excluded.
