1, plus CNC module control PLC, HMI interactive operation, simple program settings .

2, free to choose manual, semi- automatic operation mode, with memory function to store archives, you can set or modify the die-moving distance program settings, each group can be set to eight stations as a cycle, it can also be set 7654321 a station of a cycle can be more than 100 groups memory storage files.

3, the machine uses eight stations, reduced expansion pier and clamp the material can be positioned with hydraulic drive, servo motor mold transposition in convenient, mold installation, use magazine -style retooling, using front positioning.

4, using air cooling .

5, with automatic detection of errors and faults function, when there is abnormal movement or the presence of any danger the machine will immediately stop the alarming issue, show the cause, helping the operator troubleshooting.

Technical Parameters:

The main technical parameters of the project	unit	Value range
Flaring reduction capability	mm	Φ40-Φ125*2
stroke	mm	200
Rated working pressure	Mpa	14
Pump motor power	Kw	11
Station		8
Maximum molding length	mm	100
