The whole appearance intact, standard arm, standard bucket, new tires bucket intact, original paint, 90% new. Good performance. No heavy work done
Three tons Liugong 836 loaders
Operating mass: 10600kg
Rated power / speed: 92kW / 2200r / min
Bucket capacity range: 2.0m 3
Rated load: 3000kg
Maximum traction force: 100 ± 5kN
The maximum breakout force: 98 ± 5kN
Steering angle: 40 °
Rear axle swing angle: 11 °
Lifting time: 4.8 ± 0.2s
Three combined time 8.6 ± 0.2s
Climbing ability: 30
Minimum turning radius:
Outside of the bucket 5674 mm
Tire Size: 17.5-25
5173 mm outer tire
Overall length: 6880 ± 50 mm
Machine width: 2300 ± 50 mm
Overall Height: 3297 ± 50 mm
Common unloading height: 2916 ± 50 mm
Uninstall METIC: 1072 ± 30 mm
Long Unloading height: 3211 ± 50 mm
Transport position close bucket angle: 50 °
By digging depth: 42 ± 20mm
Driving speed:
4 stalls
Forward km / h35 ± 2
Back km / h14 ± 0.5
The main parameters
Standard bucket capacity 1.7m3
Engine power 92kw
Quality of work 10500kg
Optional
Optional optional parameter name
Increased bucket 2.0m 3
Plus the long arm 3214mm
Plus the long arm to increase the arm length 3214mm, bucket capacity 2.0m 3
Features:
1. Germany supercharged engine technology, efficient and reliable, high torque reserve coefficient, low fuel consumption and low emissions.
2. Liugong specializing in the design and manufacture of gearboxes and drive axle, high reliability, strong anti-overload.
3. The hydraulic system with double pump confluence steering priority, low heat, energy, action fast.
4. Large space panoramic cab can dust, noise, heat insulation, shock absorption, UV radiation, with suspension to reduce vibration, compression molding high

Sofa seats.
5. bucket used to strengthen the structure design and manufacture of ribs, which can effectively prevent the bucket bending distortion.
6. A variety of working devices to choose from.
