(kn.m)

Nominal Torque

Turning

Angle

(°)

Turning time (s)

Rated power

(kw)

hydraulic steering gear Dimension (mm)

A

B

C

D

F

G

DY63

35

28s/ 65°

5.5

2470

2320

505

350

380

694.5

DY100

35

28s/ 65°

7.5

2718

2500

505

400

420

704.5

DY160

35

28s/ 65°

11

2996

2740

505

450

420

704.5

DY200

35

28s/ 65°

15

3304

3020

505

500

550

726.5

DY250

35

28s/ 65°

15

3630

3160

505

550

550

726.5

DY320

35

28s/ 65°

18.5

3938

3400

505

600

550

726.5

DY400

35

28s/ 65°

18.5

3914

3600

560

570

600

950

DY450

35

28s/ 65°

18.5

4000

3600

560

570

600

950

DY500

35

28s/ 65°

18.5

4000

3600

560

570

600

950
