Rope Dia. (mm)

Dimensions (mm)

A

B

C

D

E

F

G

H

K

12

180

100

356

80

446

650

160

370

255

16

230

130

446

100

546

800

200

480

315

20

250

130

506

120

626

900

250

520

375

24

280

160

576

140

716

1000

260

590

432

32

300

160

676

180

836

1200

340

752

549

40

320

180

830

245

1030

1350

450

970

750

48

400

250

1018

300

1214

1700

470

1048

930

64

500

300

1320

420

1620

2298

720

1475

1280

Remark: 1. For 1 rope. 2. Free on deck, welding into bulwark
