Wire size

Sheave Dia. D (mm)

Dimensions (mm)

SWL

(KN)

Mass (Kgs)

(mm)

(Inch)

A

B

C

25

1

406

580

580

92

234

176

32

1-1/4

508

690

690

92

355

270

38

1-1/2

610

820

800

120

500

400

45

1-3/4

660

845

845

127

671

550

52

2

762

1143

1143

165

935

890

64

2-1/2

914

1130

1130

191

1414

1300

Remark: 1. Build to withstand breaking strength of indicated rope at 90°sheave warp on sheave.

2. Wrap angle 90°~180°

3. Sealed roller bearing

4. Option: 1) with load pin (Exd Proof) 2) with Horizontal roller

5. For offshore purpose
