fork type hydraulic steering gear (single rudder)
bargain
add to cartfork type hydraulic steering gear (single rudder) :
1) Suitable for:
Containers, tankers, ferries, General cargo ships, passage ships, Dredgers and any
other vessels that need more steering torque.
(2) Main Tech:
Max working torque: 15 KN. M ― 250 KN.M
Max. mech. rudder angle: ± 45 degree
Time of rudder movement: ≤28 S
Rudder stock Diameter: 300mm ― 900 mm
Working pressure: 13 Mpa ― 20 Mpa
Design pressure: 16 Mpa ― 24 Mpa
| (kn.m) Nominal Torque | Turning Angle (°) | Turning time (s) | Rated power (kw) | Dimension (mm) | |||||
| A | B | C | D | F | G | ||||
| DY63 | 35 | 28s/ 65° | 5.5 | 2470 | 2320 | 505 | 350 | 380 | 694.5 |
| DY100 | 35 | 28s/ 65° | 7.5 | 2718 | 2500 | 505 | 400 | 420 | 704.5 |
| DY160 | 35 | 28s/ 65° | 11 | 2996 | 2740 | 505 | 450 | 420 | 704.5 |
| DY200 | 35 | 28s/ 65° | 15 | 3304 | 3020 | 505 | 500 | 550 | 726.5 |
| DY250 | 35 | 28s/ 65° | 15 | 3630 | 3160 | 505 | 550 | 550 | 726.5 |
| DY320 | 35 | 28s/ 65° | 18.5 | 3938 | 3400 | 505 | 600 | 550 | 726.5 |
| DY400 | 35 | 28s/ 65° | 18.5 | 3914 | 3600 | 560 | 570 | 600 | 950 |
| DY450 | 35 | 28s/ 65° | 18.5 | 4000 | 3600 | 560 | 570 | 600 | 950 |
| DY500 | 35 | 28s/ 65° | 18.5 | 4000 | 3600 | 560 | 570 | 600 | 950 |
