HIGH SPEED FILM BLOWN EXTRUDER | Plastic Extruder

HIGH SPEED FILM BLOWN EXTRUDER | Plastic Extruder

bargain

add to cart
Product Description

Uses and Features

It is fit to puff high density and low density polyethylene industry film, farm-oriented mulch film. The cylinder and the screw stems of the extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after nitrogen treatment and precision finishing. It is double rolling and account the meter automatically.

Main Technical Variables:

MODEL

SJ-B45

SJ-B50

SJ-B55

SJ-B65

SUITABLE MATERIAL

HDPE LDPE

FILM WIDTH (mm)

200-600

300-800

400-1000

600-1300

FILM THICKNESS (mm)

HD 0.009-0.08mm

LD 0.02-0.15mm

HD 0.009-0.08mm

LD 0.02-0.15mm

HD 0.009-0.08mm

LD 0.02-0.15mm

HD 0.009-0.08mm

LD 0.02-0.15mm

MAX.EXTRUSION OUTPUT

HD 55kg/ hr

LD 60kg/ hr

HD 60kg/ hr

LD 80kg/ hr

HD 75kg/ hr

LD 100kg/ hr

HD 105kg/ hr

LD 125kg/ hr

EXTRUDER

SCREW DIAMETER (mm)

Φ45

Φ50

Φ55

Φ65

SCREW L/ D LENGTH

30: 1

SCREW MATERIAL

SACM-645/38 CRMOALA

CYLINDER MATERIAL

SACM-645/38 CRMOALA

CYLINDER COOLING

370wx2

370wx2

550wx2

550wx3

DRIVING MOTOR (Kw)

15

18.5

22

37

TEMPERATURE CONTROL

3

3

3

4

AVERAGE POWER-CONSUME (Kw)

18

26

31

45

TYPE OF DIE

DIE SIZE (mm)

Φ60/ Φ80

Φ80/ Φ100

Φ100/ Φ125

Φ125/ Φ150

TEMPERATURE CONTROL

3

AIR RING

1

AIR BLOWER (Kw)

2.2

2.2

3

5.5

CENTER STEADY STICK

2

TAKE-UPUNIT

PINCH ROLLER (DIA. WIDTH) mm

Φ165*650

Φ165*850

Φ165*1100

Φ165*1400

TAKE-UP SPEED (m/ min)

10-100

10-100

10-100

10-80

TAKE-UP MOTOR (Kw)

0.75

1.5

1.5

1.5

WINDING UNIT

TYPE

SURFACE FRICTION TYPE

WINDING MOTOR (N.m)

5

10

10

16

WINDING SPEED (m/ min)

10-100

10-100

10-100

10-80

COVER DIMENSION (m)

5.0*2.0*4.5

5.0*2.2*5.0

5.5*2.5*5.5

5.8*2.8*6.5
