Product Description
Advantages cpmparing with old style bottle unscrambler:
1)Bottle changerover part is unneceesary
2)much more economical and cost save than old style one
3)Less occupyingspace

Features
The machine is automatic controlled by PLC
The capacity is adjustable by frequency conversion
Automatic bottle feeding, unscrambling.
No need extra spare parts when change different bottles.
After the unscrambler, the bottles can be connected with air conveyor or convey belts.

Parameter
Capacity: 80-250BPM(speed adjustable)
Bottle size: Ø 40-90mm, H70-290mm(round or square bottle)
Air source: 0.7Mpa/0.4M³ / min
Power: 4KW
Oversize: 1320* 3100* 1700(mm)
Weight: 800kg
Unscramble plate: Ø 1300mm, H500mm
Main elec-parts: (frequency converter, PLC, elec-sensor, pneumatic parts, solenoid valve)
