vibration meter vm-6360

bargain

Application: used for measuring periodic motion, to check the imbalance and deflecting of moving machinery.

Is pecifically designed for present measuring various mechanical vibration. So as to provde the data for the quality control, run time and equipment upkeep.

Iuse the high-performance acceleration meter, realize the repetitiveness and accurate measurement.

It has the function of testing axle bearing situation.

Model: VM6360

Specifications:

Acceleration p 10Hz-1KHz 0.1-400m/ ms² 0.3-1312ft/ ms²

10Hz-10KHz 0.1-400m/ ms² 0.3-1312ft/ ms²

Velocity rms 10Hz-1K 0.1-400mm/ s 0.004-16.0inch

Displacement p-p 10Hz-1KHz 0.001-4.0mm 0.04-160 mil

Accuracy: (5%

Auto power off

RPM (revolution) : 5-100000r/ min

Frequency: 0.1 to 10KHz

Metric/ imperial conversion

With RS232C interface

Max hold

Operating conditions: 0-+45℃ (32℉-104℉) ,≤90%RH

Power supply: 4x1.5V AAA (UM-4) battery

Battery indicator: low battery indicator

Dimensions : 124x62x30mm

weight: 120g (not including battery)

Optional accessories: RS-232C cable & software:

1. USB adaptor for RS-232C

2. Bluetooth interface
