| Model |
| SE15L |
| Capacity | (kg) | 1500 |
| Max. Fork Height | h2 (mm) | 205 (or 195) |
| Min. Fork Height | h (mm) | 85 (or 75) |
| Fork Overall Width | m (mm) | 680 |
| Travelling Speed (With Load) | (km/ h) | 5 |
| Travelling Speed (Without Load) | (km/ h) | 6.5 |
| Overall Height | H (mm) | 1310 |
| Overall Width | W (mm) | 730 |
| Dimension | n (mm) | 360 |
| h3 (mm) | 620 |
| Wa (mm) | 1350 | 1500 |
| Overall length | L (mm) | 1650 | 1800 |
| Fork Length | l (mm) | 1000 | 1150 |
| Load Centre | C (mm) | 600 | 650 |
| Load distance | X (mm) | 795 | 945 |
| Wheel Base | Y (mm) | 1240 | 1390 |
| Net Weight (without nattery) | (kg) | 225 | 233 |
| Drive Wheel, Ployurethane |
| Motor 1200W, Wheel Ø250*80mm |
| Battery (service free) | (Ah/ V) | 80/24 |
| Battery Charger | (A/ V) | 80/24 |
| Traction Battery (option) | (Ah/ V) | - |
| Note: Specification and materials are subject to change without notice. |
